Superman Energy Drink / Water Bottling Machine SUS Easy Change Bottle Size
Superman Energy Drink / Water Bottling Machine SUS Easy Change Bottle Size
Superman Energy Drink / Water Bottling Machine SUS Easy Change Bottle Size
Superman Energy Drink / Water Bottling Machine SUS Easy Change Bottle Size
Superman Energy Drink / Water Bottling Machine SUS Easy Change Bottle Size
Superman Energy Drink / Water Bottling Machine SUS Easy Change Bottle Size
Superman Energy Drink / Water Bottling Machine SUS Easy Change Bottle Size
Superman Energy Drink / Water Bottling Machine SUS Easy Change Bottle Size
Specifications
Brand Name :
jiayuan
Model Number :
DGCF
Certification :
CE,SGS
Place of Origin :
CHINA, MAINLAND
MOQ :
1set
Price :
USD 20000 set
Payment Terms :
T/T
Supply Ability :
15 sets per month
Delivery Time :
30work days
Packaging Details :
wooden
color :
slivery white
packing material :
wooden
usage :
food and beverage
packing :
wooden
service :
top service
material :
sus
Description

equipment for a soda factory/carbonated drinks bottling plant/beer machine

Introduction

Washing part of bottle washing filling capping machine

a) Rotary pan is made of stainless steel 304.

b) The rubber clamp splice seizes the mouth of bottles, which is fixedness and reliable.

Filling part of bottle washing filling capping machine

a) Rotary pan is made of stainless steel 304

b) The way of filling is gravitation filling.

c) The filling valve is adopted best stainless steel 304

d) The structure of filling valve is reasonable, the amount is correct

e) When filling the bottle, the bottle is move but the valve is stationary. The splint of bottle-neck seizes mouth of bottles. The elevator device with the action of gear realize the up and down of bottle

Capping part of bottle washing filling capping machine

a) The dropping cap guide track fixes the device which can protect the cap from turning over and also set the device which can take out the inverse cap, equip a photo electricity switch which can

stop the machine when lacking the cap and also avoid the situation that there is bottle without cap.

b) The bottle inlet switch which is set in the capping machine, with the locking cap which is the connection of the dripping cap guide track and dialing cap pan controls the discharging of cap, making sure that stop conveyor cap when there is no bottles ,avoid the waste of cap.

Technique parameters:

Model RCGFB24-24-24-8 RCGFB32-32-32-10 RCGFB40-40-40-12 RCGFB50-50-50-15
Bottle washing head 24 32 40 50
Pulp filling head 24 32 40 50
Juice filling head 24 32 40 50
Cap screwing head 8 10 12 15
Rated production capacity 8000BPH 12000BPH 15000BPH 20000BPH
Installed capacity 6.5KW 8.7KW 9.5KW 12KW
Overall size 4070*2350*2400mm 5100*2600*2400mm 6250*3050*2400mm 7500*3900*2400mm

Superman Energy Drink / Water Bottling Machine SUS Easy Change Bottle Size

FAQ

1.Q : How to get your suitable machine or production line?

A : Find our products through zhangjiagang Jiayuan machinery co ., ltd . in google, bing, yahoo, alibaba . com ect .

Enquiry : Contact us by email , phone call , fax , instant messenger (trade manager , MSN , skype , whats app) and let us know your enquiry.

Disscussion : Specify the items you desire , confirm specification ; OEM/ODM consultation .

2.Q : What is the type of your company?

A : We are the professinal beverage machinery manufacturers to produce bottled liquids,drums,filling machine,installed cup carbonated drinks,such as filling machine. We not only sell machiners, but also sell our brand and service .

3.Q : Do you have technical support after we purchased your machines?

A : Definitely ! We will arrange our professional engineers to go aboard to your factory (company limited) , they will teach you how to install and maintenance the machines which you purchased . or help you to fix machine when it has problems .

4.Q : If you buy our machines , can you offer us wear-out spare parts?

A : No problem ! We will offer you 1 year free wear - out spare parts . As well as 1 year warranty . Once your machines broken or doesn't work within 1 year and you can't solve it . Firstly , we will try to help you to find problems from your words description by phone or other communication tolls . Secondly , if the phone solutions still not work , our engineers will go to your factory (company limited) to solve it . Meanwhile they will teach you the related experiences for fixing .

Packaging & Shipping

Superman Energy Drink / Water Bottling Machine SUS Easy Change Bottle SizeSuperman Energy Drink / Water Bottling Machine SUS Easy Change Bottle Size

Our Service

1) One year warranty for the whole system.

2) Free equipment installation and debugging.

3) After one year, we can help you to maintain the machine and the accessories are provided only one the cost price.

4) We can provide internship service and help you train the operator and mechanic.

5) Free beverage production technology and process configuration.

6) We can help you to design the product line, workshop and provide turn-key project.
