250ml Glass Bottle Beer Filling Capping Machine , Gas Cold Drink Bottle Filling Machine
250ml Glass Bottle Beer Filling Capping Machine , Gas Cold Drink Bottle Filling Machine
250ml Glass Bottle Beer Filling Capping Machine , Gas Cold Drink Bottle Filling Machine
250ml Glass Bottle Beer Filling Capping Machine , Gas Cold Drink Bottle Filling Machine
250ml Glass Bottle Beer Filling Capping Machine , Gas Cold Drink Bottle Filling Machine
250ml Glass Bottle Beer Filling Capping Machine , Gas Cold Drink Bottle Filling Machine
Specifications
Brand Name :
JIAYUAN
Model Number :
DGCF16-12-6
Certification :
CE,ISO,SGS
Place of Origin :
Jiangsu, China (Mainland)
MOQ :
1piece
Price :
US $30,000 - 560,000 / Set
Supply Ability :
10 Set/Sets per Month
Delivery Time :
30 working days
Packaging Details :
wooden box
Automatic Grade :
Automatic
Driven Type :
Electric
Power :
5.03kw
Dimension(L*W*H) :
2450*1800*2200mm
After-sales Service Provided :
Overseas service center available
Filling capacity :
2000BPH
Processing Types :
Beer,soda water,carbonated drink
Description

250ml Glass Bottle Beer Filling Capping Machine , Gas Cold Drink Bottle Filling Machine

General Description

We provide series of carbonated drink filling machine, CSD filling machine for the carbonated soft drink plant, cola filling machine, carbonated beverage filling machine.
1. Material:The material which contact direc carbonated soft drinks directly with the liquid is the SUS304 (Food grade), made in China.
2. This machine is maily for filling carbonated beverage, like Feda, sprite, coca cola, mineral water/pure water/soda water with gas, juice with gas and so on.

250ml Glass Bottle Beer Filling Capping Machine , Gas Cold Drink Bottle Filling Machine Cola, Carbonated beverage,beer,soda water
Material Shape Filling volume Filling level(mm) Neck type
Glass Bottle

Round Bottle/

Square bottle

 100ml-2L Distance from bottle neck
Customized		 Customized
Adjustable specifications of the bottle type Middle mould base: Bottle diameter ≤105mm; Bottle height≤310mm
Customers need to buy additional change-over parts for the different bottles.
If using square bottles, then bottle separating system will be added.
Carbonated Drink Preparation Syrup melting machine, Blending mixing Machine, CO2 filter, CO2 mixer.

Technique parameter:

Model: DGCF16-12-6 DCGF18-18-6 DCGF24-24-8 DCGF32-32-12
Capacity :500ml 2000 3000 8000 12000
Bottle shape: roud or square
PET bottle: (mm) (Bottle Diameter):φ50-.φ110mm (Height):150-340mm
Cap: Crown cap
Filling precision: ≤±5mm
Filling pressure:(Mpa) 0.15-0.35 0.15-0.35 0.15-0.35 0.15-0.35
Rinsing pressure:(Mpa) 0.2-0.25 0.2-0.25 0.2-0.25 0.2-0.25
Filling volume :(L) 3.5 4 6 8
Overall size:(mm) 2250*1800*2200 2450*1800*2200 2780*2200
*2350		 3600*2650
*2350		 3800*2950
*2400
Weight: (kg) 2500 3000 4000 5000 6000

Machine Structure

A. High automation level, compact structure, attractive appearance, convenient and simple operation, safe and reliable and adjustable continuous production capacity, low labor intensity.
B. The main machine adopts advanced PLC control technology
C. The key electric elements adopt products made by international famous companies, such as Mitsubishi and Siemens.
D. These series carbonated drink filling machine can handle max 3 liter pet bottle.Welcome to inspect beverage cold filling machine in our factory.

250ml Glass Bottle Beer Filling Capping Machine , Gas Cold Drink Bottle Filling Machine
Advantages

We can provide beverage filling line as below:

1. Complete pure/mineral water production line

2. Complete pure/mineral water treatment machine

3. Complete juice production line

4. Complete carbonated beverage production line

5. 5 Gallons drinking water production line.

6.End-of-line packaging system

We offer professional turnkey project from design till done of the whole project.

1.Project consultation

2.Design

3.Factory building

4.Installation

5.Commissioning

6.Training
