Specifications
Brand Name :
JIAYUAN
Model Number :
QGF-300
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
please inquire
Supply Ability :
50 sets per year
Delivery Time :
45 working days
Packaging Details :
standard wooden case
Product name :
gallon filling machine
bottle size :
3-5 gallon
capacity :
2
control :
PLC touch screen
voltage :
380V
Power :
15kw
Description

5 Gallon / 18.9L / 20L Water Filling Machine, Filling Production Line Equipment

Our QGF complete 5 gallon barrel pure,mineral water filler line mainly consists of 7 parts. They are respectively:
1.De-capping machine
2.External barrel brushing machine
3.Bottle feeding machine
4.Washing, filling, capping machine
5.Cap elevator
6.Lamp checker
7.Conveyor

The QGF series barreled water filling line is mainly used to produce bottled water with volume from 3 gallon

to 5 gallon.And different models can offer production capacity from 100 to 2000BH/H.The whole production

process operates as follows:Empty barrel are convenyed stably by conveying belt into decapping machine,

which will remove bottle caps.Those caps can be recycled after being cleaned and disinfected.Then barrel

are conveyed into the extemal brush washing machine to take all-round rinsing with hot alkali and pure water.

After rinsed,barrel will be sent to rinsing filling capping machine,where bottles are rinsed inside with hot alkali,

disinfectantliquid and pure water.And then barrel is filled with pure water provided by water treatment system.

Then after capped,those barreled water is sent to shrink packing machine in which shrink packaging of caps is

done.The whole production process is controlled by PLC,so this barreled water production line is automatic,

Through control panel,users can monitor visually working conditions of each machine section and operate conveniently.

18.9L Gallon Bottle Filler With 4 Filling Heads , Gallon Jug Filling Machine

18.9L Gallon Bottle Filler With 4 Filling Heads , Gallon Jug Filling Machine

18.9L Gallon Bottle Filler With 4 Filling Heads , Gallon Jug Filling Machine

We have different capacity

Mold QGF-150 QGF-300 QGF-450 QGF-600 QGF-900 QGF-1200
Filling heads 1 2 3 4 6 8

Capacity

(B/H)

 100 300 450 600 900 1200

Capacity

(B/H)

 18.9L

Barrel size

(mm)

 270*490

Gas pressure

(Mpa)

 0.4-0.6
Gas consumption 0.37 0.6 0.8 1 1.5 1.8

Power

(kw)

 2.2 3.5 3.5 4.5 6 7.5

Dimensions

(mm)

 1800*1900*2300 2400*1650*2500 2600*1920*2550 3100*2100*2800 3800*2800*2900 4600*2800*2800
Weight(KG) 2300 2500 3500 4500 5600 8500
