Specifications
Place of Origin :
China,JiangSu,Zhangjiagang
Brand Name :
FillPack
Certification :
CE, ISO
Model Number :
UF-6000
Driven type :
Electric
Guarantee time :
1 year
Condition :
New
Voltage :
Customised
MOQ :
1 set/pcs
Price :
Negotiation
Packaging Details :
Blanket cloth worthy sea freight
Delivery Time :
15-20 days
Payment Terms :
30% T/T deposit, 70% before shipment
Supply Ability :
30 sets/monthhttp://mao.ecer.com/images/sub_bh.gif
Description

Stainless Steel Mineral Water Treatment Machine For 6000L Per Hour

Quick Detail:

1. Flow rate: 6000L / H

2. For bottled mineral water with good ion for health

3. Main material: SUS304

4. Hollow fiber ultrafiltration system is applied, stainless steel filter membrance, UPVC pipes

Description:

This mineral water treatment system main contains the needed machines to treat the raw water to good quality mineral water in normal water line.

Main parts:

Raw water tank ---- Raw water pump---- Quartz sand filter ---- Active carbon filter---- Ion exchanger ---- Precision filter ---- Water buffer tank ---- Hollow fiber ultrafiltration ---- UV sterilizer ---- Pure water storage tank

This hollow fiber ultrafiltration adopts dissymmetrieal semipermeable film which is made from macromolecule material with special process. The raw liquid flows under pressure, inside or outside the film. The macromolecule substance and colloid particles in the raw liquid are clogged at the film surface and are brought away by circulating raw liquid. Then the liquid becomes inspissated, and further more, the substance in liquid is separated. The machine filters all the bad materials to health, and keep some minerals which good to health.

Applications:

1. The machine is mainly used to treat the to river water, well water, spring water, lake water and city water to directly drinking water for home use, factory use, or packed in bottles, barrels, other containers for market selling.

2. It is used to remove the suspended solids, bacterial, organic substance and microorganism, plastic particles, microorganisms, chlorine,taste,some heavy metal ions and so on.

3. Easy operation and good drinking water quality.

Specifications:

Model RO-6000
Flow rate ≥12m3/h (25℃)
Recovery rate ≥75%
Design pressure ≤0.15Mpa
Operation automatic control, automatic flush
Power 6kw
Size 2200*800*1750mm
Weight 600kg

For more details, please feel free to contact me.

Competitive Advantage:

1. All the stainless steel is made of high quality of SUS304 material, good guarantee of food grade for beverage production line.

2. The water treatment machines are with good polish and nice appearance.

3. For the hollow fiber ultrafiltration machine, we have UPVC and stainless steel filter pipe for choice.

4. We can make the machines customised for you.
