Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
Specifications
Brand Name :
FillPack
Model Number :
TB-250
Certification :
CE. ISO9001
Place of Origin :
China,JiangSu,Zhangjiagang
MOQ :
1 set/pcs
Price :
Negotiation
Payment Terms :
TT / LC /
Supply Ability :
1 set / month
Delivery Time :
30 days after deposit receipt
Packaging Details :
Sea worthy package
Material :
stainless steel and aluminium alloy parts
production capacity :
15000BPM
Suitable label :
PET or PVC label
Power :
2Kw
Model :
TB-250
Product name :
Shrink labeling machine
Driven type :
Electric
Weight :
700Kg
Description

15000BPH double driving four blades installed shrink labeling machine with Panasonic driver


Shrink labeling machine---Technical parameters

Model

TB-250

Input Power

2KW

Input Voltage

3,380/220VAC

Production Efficiency

250(Bottle/min)

Size of Host Machine

L2700mm x W1100mm x H2150mm

Applicable Diameter of Bottle Body

28mm-120mm

Applicable long of label

30mm-250mm

Applicable thickness of label

0.03mm-0.13mm

Applicable Internal Diameter of Paper Tube

5”-10”



Shrink labeling machine---Features

Production efficiency of equipment: 250 bottles/min
Double Contraction label feeding tray: automatically controlled by micro-computer
Automatic detection &positioning Swift and labor-saving for changing label
Absolutely precise cutting-off position


Shrink labeling machine---Electrical Appliance Configuration Specification

TB-250 is a kind high speed machine .But it adopts equivalent PLC,positioning module,servo motor and frequency converter. Besides,its touch screen is featured with a humanized operation.


Shrink labeling machine---Applicable Bottle Types

Various kinds of bottle types, for example; round bottle, square bottle, flat bottle, curved bottle and cup-oshaped, etc.

Shrink labeling machine---Description

---The shrink labeling machine is made of stainless steel and high quality of aluminum alloy, the struction is compact.
---No need to fasten feet bolts to the ground, it can be moved flexibly.
---Shrinking film volume label frame can be adjusted according to different volume label paper pipe from 5 to 10.
---Gear device can be adjusted conveniently without using tools, which makes it suitable for different bottles.
---The sleeving manner is forced sleeving which is convenient and reasonable.
---Measure system of cutting the volume label can achieve low errors.
---Knives can be changed easily and quickly with certain range.
---Bottle parting screw, location belt and conveying chian can be adjusted synchronously.
---The servo motor and high-delicacy photoelectricity from Japan make the cutting label precise


Shrink labeling machine---Technical parameter

Model TB-150 TB-250
Input power 1.5Kw 2.0Kw
Input voltage D3,380/220VAC D3,380/220VAC
Production Capacity 150(Bottle/min) 250(Bottle/min)
Size of Host Machine

L2100mm x W850mm
x H2000mm

L2700mm x W1100mm
x H2150mm
Applicable Diameter of Bottle Body D28mm-125mm D28mm-125mm
Applicable Length of Lable 30mm-250mm 30mm-250mm
Applicable Thickness of Label 0.03mm-0.13mm 0.03mm-0.13mm

Applicable Internal
Diameter of Paper Tube

 (Free Adjustment) (Free Adjustment)





Double Driving Four Blades Installed Bottle Labeling Machine With Panasonic Driver
