Specifications
Brand Name :
FillPack
Model Number :
CGF32-32-10
Certification :
CE / ISO9001 - 2008
Place of Origin :
Zhangjiagang, China
MOQ :
1 set
Price :
Negotiation
Payment Terms :
L/C, T/T,
Supply Ability :
20Sets Per Months
Delivery Time :
25 Working Days After Deposit
Packaging Details :
wooden case package
bottle type :
glass bottle with pulling cap
capacity :
10000BPH
Machine structure :
Monoblock filling machine
Material :
SUS304
Filling heads :
32
Capping heads :
10
Washing heads :
32
Product name :
Beverage bottle filler
Description

Monoblock 3 in 1 cylinder lifting type beverage bottle filler with copper ring

Monoblock 3 In 1 Water Bottle Filler Machine PLC Control And Touch Screen

Beverage bottle filler---Specifications

Bottle size 250-1500ml
Capacity 10000BPH
Suitable bottle Glass bottle with pulling cap
Control PLC control and touch screen
Certification CE;ISO

Beverage bottle filler---Description

This series of beverage bottle filler is mainly used for alcohol and all kinds of spirits filling and sealing in glass bottles with pulling cap, also according to customers' demands, to fill in PET bottles, which is with washing, filling and capping monoblock.Beverage bottle filler can fill with different capacities as requirements. Together with other assistant equipments used in the line for alcohol production line.

Beverage bottle filler---Features

1.Filling valve adopts high precision mechanical filling valve, with the character of no bottle no vacuum pumping.

2.Open gear combinated gear box transmission, with no-off device. Frequency conversion velocity modulation device extends the speed modulating scope

3.This machine has self oil lubrication device so that the lubrication points could be lubricated regularly in time. The machine is of high efficiency, low noise and long life.

4.Centering guide is of double guide bar type, with the function of pre-covering.

5.Wine jar and capping head are driven by manual, also can be driven by electricity to fit different sizes of bottles.

6.The material height in the tank is controlled by electric probe to assure the precise liquid level.

Beverage bottle filler---Model

Item

CGFF18-18-6

CGFF24-24-8

CGFF32-32-10

Capacity

6000bph(500ml)

80000bph(500ml)

10000bph(500ml)

Rising heads

18

24

32

Filling heads

18

24

32

Capping heads

6

8

10

Bottle Diameter

Commonly 50-110mm (can adjustable)

Bottle Height

Commonly 150-340mm(can adjustable)

BOTTLE

Glass or Plastic bottle

Rising pressure

0.2-0.25Mpa

Overall size

2450*1800*2350

2780*2200*2350

3600*2650*2350

Weight

3.5t

4.5t

5.5t
