Specifications
Brand Name :
FillPack
Model Number :
CGF32-32-10
Certification :
CE & ISO
Place of Origin :
China,JiangSu,Zhangjiagang
MOQ :
1 set
Price :
12000-40000USD
Payment Terms :
T/T, L/C, , MoneyGram
Supply Ability :
20 Sets Per Year
Delivery Time :
30 Working Days for water bottle filling machine
Packaging Details :
Wooden Case Package for water bottle filling machine
Control :
PLC Control With Touch Screen
Processing :
Japan & Germany
Capacity :
12000-15000BPH
Electrical Brand :
Mitsubishi, OMRON, SIEMENS
Processing type :
water bottle filling machine
Material :
Touch parts SUS304/SUS316
Machine structure :
Monoblock machine
Filling type :
Normal pressure filling
Cap Style :
Plastic Screw Cap
Description

Top covered hygeian water bottle filling machine 32 - 32 - 10 15000BPH

Quick Detail:

Machine structure

Washing, filling, capping 3 in 1 unit

Filling type

Normal pressure filling machine

Bottle type

15000BPH plasic bottles

Cap type

Bio caps: plastic screw cap & sport cap

Description:

The water bottle filling machine is one of the most pupular filling machine for filling water into plastic bottles with screw caps.

The water bottle filling machine is suitable for filling water, fresh juice etc.

Characteristics:

Machine structure

1, Washing, filling, capping in one unit

2, More compact

3, Ring type water cylinder

4, Rotary type filling machine - No residual

5, Top covered by stainless steel 304

6, UV lamb inide for killing bacteria

7, Low labor

Filling type& speed

1, More precise

2, High capacity

3, Normal pressure filling machine

Material

1, Stainless steel 304

2, Contact parts: Stainless steel 316

3, Pipe & valve connection: food grade seamless pipe

Controlling system

1, PLC cntrol

2, Touch screen

3, Solenoid valve

4, Low labor

Specifications:

Model

CGF8-8-3

CGF12-12-6

CGF18-18-6

CGF24-24-8

CGF32-32-10

Rinsing Head No

8

12

18

24

32

Filling Head No

8

12

18

24

32

Capping Head No

3

6

6

8

10

Rated

Capacity

(500ml)

2000BPH

4000BPH

7000-8000BPH

10000-15000BPH

15000-20000BPH

Overall Size

1900*1420*

2000mm

2200*1600*

2300mm

2450*1900*

2300mm

2750*1180*

2400mm

4000*2300*

2300mm

Weight

1.5T

2.2T

3.0T

4.0T

8.0T

Power

(KW)

3.0kw

3.5kw

4.0kw

4.8kw

7.6kw

Rated Voltage

Customized

Customized

Customized

Customized

Customized

General structure of water bottle filling machine for ref

Ion Re-birth Device

V

Raw Water Source > Booster Pump > Quartz Sand Filter > Active Carbon Filter > Water Softener>RO

Unit > UV Sterilizer > Pure Water Storage Tank < Ozone Machine

(Steam Generator)

V

Bottle Blowing System > Monoblock Water Filling Machine > Labeling machine > (Shrinking Tunnel)>Code

Printer > Shrink Wrapping Machine

*** *** *** *** *** *** *** *** ***
