Specifications
Brand Name :
FillPack
Model Number :
RO-500L
Certification :
CE,ISO
Place of Origin :
ZhangJiaGang City, JiangSu Province, China
MOQ :
1 set/pcs
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, , MoneyGram
Supply Ability :
50 sets/month
Delivery Time :
20-25days
Packaging Details :
sea worthy packing
Treatment Ro Level :
Single Level
Key words :
water treatment equipment line
Capacity :
500L Per hour
Guarantee Time :
One Year
Function: :
water purification
Material :
Stainless Steel 304
Description

Description of our our 500L Reverse Osmosis drinking water purification systems / filter / equipment / machine

The reverse osmosis device is an equipment to purify the saltine water with the action of pressure difference of semi permeable membrane. It is called reverse osmosis, as it is counter to natural penetration direction. Different materials have different osmotic pressures. The reverse osmosis method to adopt larger osmotic pressures is used to obtain the purpose to separate,extract, purify and condense.
More than 97% soluble salts and 99%glues, microbe, particulate and organic substances and etc can be removed with the reverse osmosis. It becomes the most idea equipment for the modem program of pure water, hyper pure water, and airspace water. The remarkable characteristics of the equipment are shown as lower energy consumption, no pollution, simple techniques, high water quality, easy operation and maintenance.

Pure Drinking / Drinkable water purify/ Reverse Osmosis filtration equipment / plant / machine / system / line

SS304 500L Reverse Osmosis Purification System Multi Medium
SS304 500L Reverse Osmosis Purification System Multi Medium
Working process of water ro system:

1. Raw water pump-- provide the pressure to quartz sand filter/active carbon filter.
2. Multi-medium filter-- get rid of turbidity, suspended matter, organic matter, colloid, ect
3. Active Carbon filter--Remove the color, free chloride, organic matter, harmful matter, ect.
4. Softener--exchange "ions" of calcium and magnesium with the most common and easiest method.
5. Micron filter--prevent large particles, bacteria, viruses into RO membrane, accuracy is 5um,
6. High pressure pump-- Provide the high pressure to RO membrane ro.
7.RO system-- main part of the plant. The RO membrane's desalting rate can reach 99%, removing over 99% ions.
Parameters:
Model
Capacity
Motor Power
Membrane
Dimension
Weight
RO-500
500L/H
1.47KW
4040
1400*600*1600mm
150kg
RO-1000
1000L/H
2.57KW
4040
1600*800*1800mm
200kg
RO-2000
2000L/H
3.75KW
4040
1900*1000*1950mm
300kg
