Specifications
Brand Name :
FillPack
Model Number :
KLCGF18-18-6
Certification :
CE & ISO & TUV & SGS
Place of Origin :
China,JiangSu,Zhangjiagang
MOQ :
1 set
Price :
Negotiation
Payment Terms :
TT & L/C, D/A, D/P, T/T, , MoneyGram
Supply Ability :
20 sets/month
Delivery Time :
30 Working Days After Receiving Your Deposit Payment
Packaging Details :
Wooden Case Package
Weight :
5000-7000 kg
Dimension(L*W*H) :
2800*2150*2300 mm
Filling pressure :
0.1-0.35Mpa
Automatic Grade :
Automatic
Bottle type :
PET Plastic Bottle
Condition :
New
Material :
SUS304
Filling precision :
≤+/-1mm(liquid level)
Processing Types :
Granular juice processing filling packing
Voltage :
380V/220V 50HZ
Filling Material :
Juice with paste granule
Capacity :
5000-7000BPH
Control :
PLC Control With Touch Screen
Suitable Bottle Size :
0.3-2L PET Bottle
Cap Style :
Plastic Screw Cap
Warranty :
1 Year for Spare Parts
Description
Product Description

Complete line include Juice Filling Machine and mixing processing packing labeling​

>>>Overview of Production Line:
Drinking Water Treatment Equipment → Syrup pot → Syrup Filter → juice mixing tank → Vacuum degasser → Homogenizer → UHT(Sterilization) → Washing, Filling, Capping 3-in-1 Machine For Filling Juice → Bottle Inverted Conveyor Sterilization → Spray Water Sterilization.(85℃) → Labeling Machine Code printer → Shrink wrap packing machine→ Finished Products

Granular Juice Processing System

1, Juice batching system: sugar pot, batching tank, duplex filter, homogenizer, vacuum degasser, tubular ultra-high temperature sterilizer, heat preservation tank.

2, The heating method can be steam heating, sugar melting pot, ingredient tank and beverage heat preservation tank can be made into three layers of heat preservation treatment, the outermost layer is heat preservation cotton, the middle layer is steam layer, and the latter layer is material, so the heating speed is fast, the heat loss is small, and the cost can be greatly reduced, so a steam boiler needs to be configured.
Complete line include Juice Filling Machine and mixing processing packing labeling
Washing, Filling, Capping 3-in-1 Machine For Filling Juice
This machine is used to produce granular juice for plastic bottle, there is seperate particle filler, which can fill granule pulp or particle, the machine combine rinser, juice filler, granule filler and capper in one unit, suitable to produce granular juice, dairy drink, tea drink, flavor drink, and other non-carbonated drink.
Complete line include Juice Filling Machine and mixing processing packing labeling
Washing Filling Capping 3-in-1 in the Granular Juice filling line
Model KLCGF12-12-4 KLCGF18-18-6 KLCGF24-24-8 KLCGF32-32-12 KLCGF40-40-12
Capacity 4000BPH 5000-7000BPH 8000-12000BPH 12000-15000BPH 15000-20000BPH
Bottle shape (Bottle Diameter):50-110mm (Height):160-320mm
PET bottle PET screw
Filling precision ≤+/-1%
Filling pressure 0.15-0.35MPa 0.15-0.35MPa 0.15-0.35MPa 0.15-0.35MPa 0.15-0.35MPa
Rinsing pressure 0.2-0.25MPa 0.2-0.25MPa 0.2-0.25MPa 0.2-0.25MPa 0.2-0.25MPa
Power 4.4Kw 4.4Kw 5.2Kw 6.2Kw 7.8Kw
Size(mm) 2100*1750*2200 2800*2150*2300 3100*2450*2300 3800*2800*2500 4100*3000*2500
Weight(Kg) 3500 5000-7000 8000-12000 12000-15000 15000-20000
If you need non-granular juice filling line, please check them on our website or contact the sales consultant directly.
Other machines in the production line

Water treatment system
★ Capacity range: 250L—30T per hour can be chosen.

Vacuum degasser
★ After degassing, the juice beverage can reduce or avoid the oxidation of juice components, and reduce the change of color and flavor of juice.

Homogenizer
★ The shelf life is also improved, 3-5 times longer than the original. The products are of good quality.

Washing Filling Capping Heads
★ Direct connection technology is used between air conveyor and in-feeding starwheel to substitute in-feeding screw and conveyor. It is easy to change the size of bottles.
★ The head of filling machine is made of better stainless steel, which is firm and endurable.

Labeling machine with code printer

Film shrinking packing machine
★ How to choose the machine? You need to tell us what kind of film you need and what kind of bottle arrangement you need.
