Pure Drink / Drinking / Drinkable Water Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
Specifications
Brand Name :
FillPack
Model Number :
FP-2000S
Certification :
CE. ISO9001
Place of Origin :
China,JiangSu,Zhangjiagang
MOQ :
1 set/pcs
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, , MoneyGram
Supply Ability :
1 set / month
Delivery Time :
35-40 days after deposit receipt
Packaging Details :
Sea worthy package
Bottle volume :
100-2000ml
Weight :
13000kg
Output :
2000-2500BPH
Cavitiy :
2 Cavities
Application :
PET bottle
Automatic :
Yes
Blow moulding type :
Stretch blow moulding
Voltage :
380V/220V 3 phase 50HZ / 60HZ / Customized
Warranty :
1 year
Condition :
New
After-sales service provided :
Engineers available to service machinery overseas
Description

Servo automatic 2 Cavity PET bottle blow molding machine

>>> Product Introduction:

FP-2000S servo automatic 2 Cavity PET bottle blow molding machine is suitable for blowing PET bottles of various shapes, volume from 100ml to 2000ml, wide application for blowing mineral water bottles, soda bottles,cola bottles.etc.

>>> Product Features:

1. Produce bottle from 0.1L to 2L (2cavity)
2. Output capacity up to 2500BPH for 0.5L bottles using two-cavity blow mould
3. Advanced PLC control system with a user-friendly panel and time-control precision of PLC up to 0.01second
4. Equipped with special designed air storage unit
5. Using Infrared preform heater
6. Independent Temperature Control for different heating lamp to get ideal preform heating results
7. Heating lamps are adjustable in directions to suit various preforms.
8. Operated only by one person without special training.
9. Simple installation & startup adjustment.
10. Waste rate of finished bottle is less than 0.2%

Pure Drink / Drinking / Drinkable Water Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
>>> Flow and Auxiliary machines:
HP Air Compressor → Air Tank → Air Filter →Air Dryer → Air Filter → Chiller → LP Air Compressor →Automatic Bottle Blowing Machine

1. Auxiliary Machine To operate this PET blowing machine, it also need some auxiliary machines. such as air compressor, air filter, air dryer, chiller and so on. we will equip the auxiliary machine according to your need.
2. Bottle Preform If you need, we can also help you find the bottle preform in china.

>>>Technical Paramters:

Model
FP-2000S
Container
Production material
PET
Volume
0.1-2L
Theoretical output
2000-2500PCS/H(6L)
Applicable bottle body diameter
20-92mm
Applicable bottle height
50-350mm
Moulding
Max.mould plate Dimension
450x490mm
Max. mould thickness
180mm
Machine size and weight
Main machine(L*W*H)
2500*1650*1850mm
Main machine weight
3200kg
Preform unscrambler (L*W*H)
2000*950*2480mm
Heater weight
250kg
Install Power-Using power
18kw
N/M
item name
BRAND
ORIGINAL PLACE
1
PLC controller
DELTA
Taiwan
2
TOUCH SCREEN
DELTA
TAIWAN
3
Pneumatic components
FESTO
GERMANY
4
Pneumatic components
AIRTAC
TAIWAN
5
Photoelectric signal switching
OMRON
JAPAN
6
control button
OMRON
JAPAN
7
AIR FILTER
DELTA
TAIWAN
8
Electromagnetic valve
PMC
KOREA
9
High pressure muffler silencer
SMC
JAPAN

Pure Drink / Drinking / Drinkable Water Bottle Blow Manufacturing Machine / Equipment / Line / Plant / System
