Pure Drink / Drinking / Drinkable Water Bottle Blow Moulding / Molder / Molding Machine / Equipment / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Moulding / Molder / Molding Machine / Equipment / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Moulding / Molder / Molding Machine / Equipment / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Moulding / Molder / Molding Machine / Equipment / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Moulding / Molder / Molding Machine / Equipment / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Moulding / Molder / Molding Machine / Equipment / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Moulding / Molder / Molding Machine / Equipment / Plant / System
Pure Drink / Drinking / Drinkable Water Bottle Blow Moulding / Molder / Molding Machine / Equipment / Plant / System
Specifications
Brand Name :
FillPack
Model Number :
FP-6000DS
Certification :
CE. ISO9001
Place of Origin :
China,JiangSu,Zhangjiagang
MOQ :
1 set/pcs
Price :
Negotiation
Payment Terms :
L/C, D/A, D/P, T/T, , MoneyGram
Supply Ability :
1 set / month
Delivery Time :
35-40 days after deposit receipt
Packaging Details :
Sea worthy package
Max. bottle volume :
2L(100-2000ml)
Weight :
3500Kg
Dimension :
3900*900*2500mm
Output :
9500-10000BPH
Cavitiy :
6Cavities
Power :
51kw
Condition :
New
Application :
PET bottle
Automatic :
Yes
Blow moulding type :
Stretch blow moulding
Voltage :
380V/220V 3 phase 50HZ / 60HZ / Customized
Warranty :
1 year
After-sales service provided :
Engineers available to service machinery overseas
Description

Automatic servo linear 6 cavity blow molding line

>>> Product Introduction:

FP-6000DS 6 cavity Full automatic blow molding machine is suitable for producing PET plastic containers and bottles in all shapes. It is widely used to produce the carbonated bottle, mineral water, pesticide bottle oil bottle cosmetics, wide-mouth bottle and hot fill bottle etc.

Our new design PET bottle machine with below high-tech can save 130000kwh electric one year for customer compare with normal linear four cavity blowing machine.

>>> Product Features:

1). Stable performance with advanced PLC.
2). Automatic preform conveyer to save human cost.
3). Preform self-rotation and infrared pre-heater revolution assure the even distribution of heat, which improve the bottle shaping rate, increase the production.
4). High adjusting performance to enable preheat the preforms perfectly by adjust the voltage control area in the PLC, which could adjust the temperature of the infrared lights in the pre-heater, and keep the proper temperature and humidity invariable.
5). High safeties with security automatic-locking device in each mechanical action, which will make the production into a perfect safe environment, in case of the breakdown in certain procedure.
6). Introduce the FESTO air cylinder to avoid contamination and noise.
7). Satisfaction with different atmospheric pressure for blowing and mechanical action by dividing the blowing and action into three parts in the air pressure diagram of the machine.
Pure Drink / Drinking / Drinkable Water Bottle Blow Moulding / Molder / Molding Machine / Equipment / Plant / System
>>> Flow and Auxiliary machines:
HP Air Compressor → Air Tank → Air Filter → Air Dryer → Air Filter → Chiller → LP Air Compressor → Automatic Bottle Blowing Machine

1. Auxiliary Machine To operate this PET blowing machine, it also need some auxiliary machines. such as air compressor, air filter, air dryer, chiller and so on. we will equip the auxiliary machine according to your need.
2. Bottle Preform If you need, we can also help you find the bottle preform in china.
3. PET Bottle Mold Our PET blowing machine can produce various shape bottles. we can according to your need to design your own bottle and make mold for you.
4. Preform & Cap Molds We also can provide you with preform mold and cap mold according to your demand.

Specifications:

Model
FP-6000DS
Container
Applicable Preform Height/Neck
<330mm/25mm,28mm,30mm
Applicable Bottle Volume/Height/Diameter
Max.2Liter/Max.328mm/Max.105mm
Theoretical output
9500-10000PCS/H(based on 500ml)
Applicable bottle body diameter
20-92mm
Applicable bottle height
50-350mm
Electric consumption
Install power
51kw 380v 3Phase /220v 3Phase 50/60HZ
Heating oven power/Heating Oven operating power
46kw/26kw
Machine size and weight
Machine size
3900*900*2500mm
Main machine weight
3500Kg
Sorting machine/Loader
2000*1500*1500mm/3000*1000*1500mm
Blowing Main machin
3600*1600*2300mm
Blowing mould
6 cavity

Pure Drink / Drinking / Drinkable Water Bottle Blow Moulding / Molder / Molding Machine / Equipment / Plant / System
