Specifications
Brand Name :
FILLPACK
Model Number :
BZCLB-1/BZCLB-2/BZCLB-4
Certification :
CE/ISO9001
Place of Origin :
Zhangjiagang, China
MOQ :
1 set
Price :
45USD-255USD
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
20 Sets Per Months
Delivery Time :
7 Working Days After Deposit
Maximum range :
5-4500ML
Maximum flow :
4.5L/min-18L/min
Power :
90-360W
Filling accuracy :
±1%
control method :
Manual, Automatic
cooling method :
air cooling
Anti-drip function :
YSE
Power off memory function :
YES
Description

Semi Automatic Horizontal Magnetic Pump Alcoholic Beverage Bottling Oil Liquid Water Filling Machine

Instructions:

Magnetic pump type filling machine is suitable for liquid filling.

Bracket installation refer to the above picture installation;

Function introduction:

A, [filling time]: adjust the time of the pump work; control the amount of filling;

B, [waiting time]: the interval between the first and second automatic filling state; used in the automatic filling state;

C, [Counter]: Memorize the amount of production within a certain period of time;

D, [Filling speed]: Adjustment of dosing time;

E, [Filling setting]: Automatically set the filling amount button; when the machine is switched on, start the filling setting; when the amount of machine filling reaches the amount you need; Repress filling setting, the machine automatically memorizes the filling time; so the amount of filling is set;

F, [Manual]: manual state switching and use of electric filling key switch;

G, [Auto]: Automatic state switching and use of automatic filling key switch

Easy to use instructions: start the machine; put the container you need under the discharge port; start the filling setting and start the filling; when the material is filled to the position or weight you need; turn off the filling setting;This machine will automatically memorize your filling volume; then choose [automatic] or [manual] to start work;

Performance and Features:

1. LCD liquid crystal display, panel operation more convenient and simple

2. Outlet nozzle anti-drip design, filling high precision, accurate measurement.

3. Automatic counting function, effective control of the number of filling.

Parameters:

Model 1 head 2 heads 4 heads
Power 90W 180W 360W
Maximum range 5ml-4500ml 5ml-4500ml 5ml-4500ml
Maximum flow 4.5L/min 9L/min 18L/min
Filling accuracy ±1% ±1% ±1%
control method Manual, Automatic Manual,Automatic Manual,Automatic
cooling method air cooling air cooling air cooling
Anti-drip function yes yes yes
Power off memory function yes yes yes
Total Weight 10kg 15kg 40kg

Semi Automatic Oil Liquid Water Filler Horizontal Magnetic Pump Alcoholic Beverage Bottling

Semi Automatic Oil Liquid Water Filler Horizontal Magnetic Pump Alcoholic Beverage Bottling

Semi Automatic Oil Liquid Water Filler Horizontal Magnetic Pump Alcoholic Beverage Bottling
