3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding
3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding
3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding
3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding
3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding
3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding
3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding
3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding
3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding
3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding
Specifications
Brand Name :
FILLPACK
Model Number :
KP-40
Certification :
CE/ISO9001
Place of Origin :
Zhangjiagang, China
MOQ :
1 set
Price :
1600USD
Payment Terms :
L/C, D/A, D/P, T/T, MoneyGram
Supply Ability :
20 Sets Per Months
Delivery Time :
15 Working Days After Deposit
Speed :
20-200pcs/min
Label Height :
15-150mm
Label Length :
25-300mm
Bottle diameter :
20-140mm
Bottle type :
round/flat/square bottle
Label position :
single label
Dimension :
128*80*80cm
Label Roll :
75--250mm
Material :
Stainless Steel
Warranty :
1 Year
Description

Table Top Type Plastic Cup Labeler Labeling Machine for round bottle With Hot Foil Coding Automated Adhesive Sticker

1.Bottle Labeling Machine composition:

Electrical cabinet, Conveyor, Roll label device, Brush label device, labeling engine, Operation system and control system;

2. Equipment function characteristics:

(1) Control system:PLC control system, with high stable operation and extremely low failure rate;

(2) Operation system:Touch screen, with Chinese and English language, rich with help function and fault display function,easy operation;

(3) Check system:Check label and bottle sensor, Desktop check label position, stable and convenient don’t have much higher requirement for the worker skill;

(4) Alarm function : such as label spill, label broken or other malfunction during machine working all will alarm and stop working.

(5) Machine Material:The machine and spare parts use material stainless steel and anodized senior aluminum alloy,with high corrosion resistance and never rust;

3. Working process:

1 Worker put bottle on conveyor and delivery to labeling engine one by one;

2 When sensor check bottle, send signal to PLC, PLC received the signal deal with information first, then output signal to servo motor driver, driven by the drive motor send label.

3 The brush label device past label on bottle one side first, then bottle rolling around in the roll label device, brush label on bottle body for around, labeling finish.

4. Technical parameter:

Model KP-40
Accuracy ±1mm
Speed 20-200pcs/min(according to the size of the bottle and the length of the label )
Label Height 15-150mm
Label Length 25-300mm
Bottle diameter 20-140mm
Accuracy ± 1mm (according to the bottle)
Label Roll 75--250mm
Power AC110V/220V 50/60HZ 1000W
Dimension 128*80*80cm
180kg


5.Details

3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding

3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding

application:

3000BPH Table Top Automated Adhesive Sticker With Hot Foil Coding

7.Electrical Components:

No NAME QTY. Brand Origin
1 Photoelectric 1 Autonics Korea
2 Measuring object electric eye 1 Autonics Korea
3 touch screen(7-inch color all-in-one screen) 1 / China
4 Label motor (stepping) 1 Jamek China
5 Conveyor motor 1 / China
6 spoke motor 1 / China
7 switch 1 Chint China
8 switching power supply 1 / China
