12KG PE Film Small Liquid Honey Sachet Packing Machine 10 Micron
12KG PE Film Small Liquid Honey Sachet Packing Machine 10 Micron
12KG PE Film Small Liquid Honey Sachet Packing Machine 10 Micron
12KG PE Film Small Liquid Honey Sachet Packing Machine 10 Micron
Specifications
Brand Name :
FillPack
Model Number :
5LA1, 10LA1
Certification :
CE / ISO9001
Place of Origin :
Zhangjiagang, China
MOQ :
1 set
Price :
7550-9350USD/set
Payment Terms :
L/C, D/A, D/P, T/T, , MoneyGram
Supply Ability :
20 Sets Per Months
Delivery Time :
20 Working Days After Deposit
Packaging Details :
sea worthy packing
Model :
5LA1, 10LA1
Packing speed: :
4-6 bags/min
Bag width: :
270mm or 380mm
Film length: :
150mm+, adjustable
Filling range: :
2-12KG
Edge banding type: :
back sealing type
Total power: :
5.5KW
Film width: :
Max. 820mm
Description

II Description: 2-12KG PE film Sachet liquid pure water juice milk packing machine

General:

1, Application: Automatic liquid packaging machine is a liquid packaging equipment suitable for all kinds of liquid without gas, especially soy, wine, vinegar, juice, fruit pulp, soybean milk, peanut oil, vegetable oil, plant oil, mineral water, and liquid chemical products.

2, Sealing style: back sealing

3, Function:The equipment can automatically complete periodic operations such as bag making, filling, sealing, cutting and counting.

4, Whole machine with stainless steel covering, With foot wheels for easy transper;

5, The conveying part can be automatically connected to the packaging operation. It can avoid manual handling and save cost.

III Technical specifications:

Model 5LA1 10LA1
Bag length (mm) 150-450 Adjust by weight
Bag width (mm) 270 380
Packaging film width (mm) Max. 620 Max. 820
Packing film thickness (micron) 8-10 12
Package weight (kg) 2-5 5-12
Packing speed (bags/min) 4-6 4-5
Power (kw) 5.5 (380V/220V 50HZ) 5.5 (380V 50HZ)
External dimensions (mm) 1300*2000*2200 1320*2020*2220
Weight (kg) 380 400

Packaging Effects:

12KG PE Film Small Liquid Honey Sachet Packing Machine 10 Micron 12KG PE Film Small Liquid Honey Sachet Packing Machine 10 Micron


Struction design:

12KG PE Film Small Liquid Honey Sachet Packing Machine 10 Micron

IV Options

Option 1.1.1

Producr picture: Technical specifications:

12KG PE Film Small Liquid Honey Sachet Packing Machine 10 Micron

Item Name:

 Ink jet code printer

Model:

 OH-338
Inkjet printing precision: 200DPI

Capacity:

 up to 75 m/min
Dimension: 347 x220x 100 mm

Option 1.1.2

Packaging film parameters:

Material: PE-LD
Printing: Customized LOGO
Width:

620mm (suitable for up to and including 5L);

820mm (suitable for 12L)
Thickness: 80micron,100micron,120micron
Sachet volume: From 2000ml to 12000ml
Packing detail: 1ton have 1.72cbm,20' container could load about 15tons.
Application: water pouch packaging, water sachets, pure water packaging, mineral water packaging, flavoured water bag packaging, Juice packaging, water bags packaging

12KG PE Film Small Liquid Honey Sachet Packing Machine 10 Micron

Option 1.1.3

Producr picture: Technical specifications:

12KG PE Film Small Liquid Honey Sachet Packing Machine 10 Micron

Item Name:

 Belt conveyor

Power:

 1.5KW

Capacity:

 50-300mm/s
Dimension: 2000*600*500mm
