ISO9001 Table Type Sticker Labeling Machine round Bottles Label Maker Machine
ISO9001 Table Type Sticker Labeling Machine round Bottles Label Maker Machine
ISO9001 Table Type Sticker Labeling Machine round Bottles Label Maker Machine
ISO9001 Table Type Sticker Labeling Machine round Bottles Label Maker Machine
ISO9001 Table Type Sticker Labeling Machine round Bottles Label Maker Machine
ISO9001 Table Type Sticker Labeling Machine round Bottles Label Maker Machine
ISO9001 Table Type Sticker Labeling Machine round Bottles Label Maker Machine
ISO9001 Table Type Sticker Labeling Machine round Bottles Label Maker Machine
ISO9001 Table Type Sticker Labeling Machine round Bottles Label Maker Machine
ISO9001 Table Type Sticker Labeling Machine round Bottles Label Maker Machine
ISO9001 Table Type Sticker Labeling Machine round Bottles Label Maker Machine
ISO9001 Table Type Sticker Labeling Machine round Bottles Label Maker Machine
Specifications
Brand Name :
FILL PACK
Model Number :
KP-40
Certification :
CE / ISO9001 - 2008
Place of Origin :
Zhangjiagang, China
MOQ :
1 set
Price :
USD $1600/set
Payment Terms :
L/C, D/A, D/P, T/T, MoneyGram
Supply Ability :
15 Sets Per Months
Delivery Time :
30 Working Days After Deposit
Packaging Details :
Sea worthy package
Dimension of applicable label: :
15≤width≤150mm,length≥10mm
Labeling speed: :
20-200pcs/min
label :
Adhesive
side :
Single Side
Applicable bottle: :
Round bottle
Dimension of applicable bottle :
Width≥20mm,length≥20mm,20≤height≤350mm
Description

Table type sticker labeling machine/ label maker machine round bottles

Equipment composition:

Electrical cabinet, Conveyor, Roll label device, Brush label device, labeling engine, Operation system and control system;

Equipment function characteristics:

(1) Control system:PLC control system, with high stable operation and extremely low failure rate;

(2) Operation system:Touch screen, with Chinese and English language, rich with help function and fault display function,easy operation;

(3) Check system:Check label and bottle sensor, Desktop check label position, stable and convenient don’t have much higher requirement for the worker skill;

(4) Alarm function : such as label spill, label broken or other malfunction during machine working all will alarm and stop working.

(5) Machine Material:The machine and spare parts use material stainless steel and anodized senior aluminum alloy,with high corrosion resistance and never rust;

Working process:

1 Worker put bottle on conveyor and delivery to labeling engine one by one;

2 When sensor check bottle, send signal to PLC, PLC received the signal deal with information first, then output signal to servo motor driver, driven by the drive motor send label.

3 The brush label device past label on bottle one side first, then bottle rolling around in the roll label device, brush label on bottle body for around, labeling finish.

4. Technical parameter:

Model KP-40
Accuracy ±1mm
Speed 20-200pcs/min(according to the size of the bottle and the length of the label )
Label Height 15-150mm
Label Length 25-300mm
Bottle diameter 20-140mm
Accuracy ± 1mm (according to the bottle)
Label Roll 75--250mm
Power AC110V/220V 50/60HZ 1000W
Dimension 128*80*80cm
180kg
