Steam Jacket Heating Juice Processing Equipment With Agitator
Steam Jacket Heating Juice Processing Equipment With Agitator
Steam Jacket Heating Juice Processing Equipment With Agitator
Steam Jacket Heating Juice Processing Equipment With Agitator
Steam Jacket Heating Juice Processing Equipment With Agitator
Steam Jacket Heating Juice Processing Equipment With Agitator
Steam Jacket Heating Juice Processing Equipment With Agitator
Steam Jacket Heating Juice Processing Equipment With Agitator
Steam Jacket Heating Juice Processing Equipment With Agitator
Steam Jacket Heating Juice Processing Equipment With Agitator
Specifications
Brand Name :
FillPack
Model Number :
2000LPH
Certification :
CE,ISO
Place of Origin :
China,JiangSu,Zhangjiagang
MOQ :
1 set/pcs
Price :
$2,590.00/set
Payment Terms :
30% T/T deposit, 70% before shipment
Supply Ability :
50 sets/month
Delivery Time :
15 days
Packaging Details :
The mixing tank is packed by wrapping film.
Type: :
Beverage processing equipment
Material: :
SUS304, SUS316
Mixer Type: :
Agitator
Material Processed: :
Chemicals, Food, Medicine
Features: :
Three layers
Working processing: :
Mixing
Description

Factory Direct Sale Steam Jacket Heating Liquid Mixer Mixing Tank With Agitator

Steam heating jacket mixing tank application:

This steam heating jacket mixing tank is used to mixing material like juice, milk, drink, chemicals, cosmetics and so on. It is with electric mixer and the motor could be regulated. It adopts the high quality of SUS304 material and meet with the food grade. It is easy to operate and washing. Also it could be set with automatic CIP spraying head for more easy washing. the heating method, we use steam heating. Steam heating jacket mixing tank including: 1, quick open manhole at top 2, anti foaming liquid inlet, 3, CIP cleaning head, 4, dust proof respirator, 5, glass lever gauge 6, sampling valve 7, anti rotational flow outlet 8, low liquid lever sensor 9, height adjustable stand 10, Inclined oar agitator

Steam heating jacket mixing tank parameter:

Capacity
500LPH
1000LPH
2000LPH
3000LPH
4000LPH
5000LPH
6000LPH
Material
SUS304
Pressure
0.6Mpa
Structure
inner layer+middle layer+insulation+outer layer
Heating way
Steam heating
Motor power (kw)
0.75
0.75
1.1
1.5
2.2
3
6
Motor speed (rpm)
35
Inner thickness(mm)
3
Middle layer
thickness(mm)
1.5
Insulation thickness(mm)
50
Outer thickness(mm)
1.5
Insulation material
Polyurethane foam
Manhole diameter(mm)
400
Diameter of inlet&outlet(mm)
38
38
38
38
38
51
51
Dimension of tank body(mm)
800*1000
1100*1220
1450*1200
1600*1500
1600*2000
1660*2300
1800*2400
Total Height(mm)
2100
2420
2420
2700
2900
3200
3300
Weight(KG)
310
400
600
700
800
900
950

Steam Jacket Heating Juice Processing Equipment With Agitator
