CNC Threading Machine For PVC PP PE PPR Pipes Production Line
CNC Threading Machine For PVC PP PE PPR Pipes Production Line
CNC Threading Machine For PVC PP PE PPR Pipes Production Line
CNC Threading Machine For PVC PP PE PPR Pipes Production Line
CNC Threading Machine For PVC PP PE PPR Pipes Production Line
CNC Threading Machine For PVC PP PE PPR Pipes Production Line
Specifications
Brand Name :
SUNTECHMACH
Model Number :
STLC-200
Certification :
CE
Place of Origin :
CHINA
MOQ :
1 set
Price :
USD12900.00
Payment Terms :
T/T
Supply Ability :
10 sets
Delivery Time :
10-20DAYS
Packaging Details :
Wooden case
Diameter :
100-200mm
Material :
plastic pipe PVC PP PE
Capacity :
200mm 8 INCH
Function :
Threading Machine for PVC PP PE PPR Pipes
For :
All plastic pipes threading
Warranty :
12 month
Description

Threading Machine For PVC PP PE PPR Pipes Production Line Pipe Extrusion Plant

Threading Machine for PVC PP PE PPR Pipes

Plastic pipe threading machine Application

Plastic pipe threading machine is specially designed and developed in order to make thread on plastic

pipe which adapt to the current hardware plumbing, chemical and agricultural drainage and irrigation

departments pipe line.

It is for plastic pipe end inner and outer circle for thread processing and forming connection. The machine

is controlled by CNC, it can process the threaded pipe automatically, you only need to change the program

to process the pipe with different diameter. Using this type plastic PVC pipe threading machine is fast, high

efficiency and the thread quality is good, it can make a variety of different teeth type, teeth distance for

casing, pipe, mining pipe as well as water pump pipes.

Plastic pipe threading machine Technical Data

Plastic pipe threading machine for PVC,PP,PE pipe

Model: STLC-200

CNC system: Made in China or Fanuc in option, 8.4 TFT screen, with hand wheel, pitch compensation

Machining diameter: 100-200mm outer threading (inner threading also available)

Capacity: 30,60,90,degree teeth, can customize according to client given thread name

Automation grade: Semi-automatic, need worker to feed and pick out pipe, the other process are automatic

Main shaft: 3kw main shaft motor 1pc, main shaft reducer 1pc, encoder 1pc, main shaft speed is adjustable

Blade spindle: 1.5kw blade spindle motor, full copper motor 2pcs

Electrical units: DELIXI etc.

X axis and Y axis servo motor 2.0kw, 2000rpm, torque 7.7mm

Material: Made of Carbon steel

Pipe diameter: Worker can adjust the clamping to fit different diameters of pipes

Control: Blade spindle drive the blade to rotate and cut the thread

Speed: 30-40sec/each pipe

Package: 1 woodencases/set

Plastic pipe threading machine Selling feature

Other size in option

The maximum diameter of machine can be customized according to client requirement..
