Specifications
Place of Origin :
CHINA
Brand Name :
QDGY
Certification :
TS16949,ISO9001,DOT SAE J1401,FMVSS106
Model Number :
GSG111
MOQ :
1000
Price :
negotiation
Packaging Details :
200 into cartons
Delivery Time :
within 30 days
Payment Terms :
T/T,L/C
Supply Ability :
90000000
Description

3.2mm internal diameter and 10.5mm outside diamter size dot OEM approved SAE J1401 FMVSS10

3.2mm internal diameter and 10.5mm outside diamter size dot OEM approved SAE J1401 FMVSS10

-- Product Description --- www.qdgybrakehose.com

3.2mm internal diameter and 10.5mm outside diamter size dot OEM approved SAE J1401 FMVSS103.2mm internal diameter and 10.5mm outside diamter size dot OEM approved SAE J1401 FMVSS10

3.2mm internal diameter and 10.5mm outside diamter size dot OEM approved SAE J1401 FMVSS10

Rubber Brake Hose Specifications:

Inner Diameter Outer Diameter Outer layer Double braid Inner layer
1/8" (3.2mm) 0.413" (10.5mm) EPDM PVA EPDM
3/16" (4.8mm)

0.492" (12.5mm)

Rubber Brake Hose Features:

  • Two braid PVA reinforced hose
  • Meets FMVSS-106 and SAE J1401 specifications
  • Every brake hose pressure tested to 3500 psi( 240 bar or 24Mpa )
  • Burst pressure:minimum 7250 psi ( 500 bar or 50Mpa )
  • Temperature range -50°C to 121 °C
  • Compatible with DOT3,DOT4 and DOT4+ brake fluides

Rubber Brake Hose Advantages:

  • Built to DOT and SAE automotive industry quality and safety standards.

  • Hoses constructed of EPDM rubber and PVA braid, offering high dynamic strength and chemical & thermal resistance

  • Brake Hoses with banjo end fittings are packaged with new copper washers to assure proper sealing.

  • Brake Hoses tested up to 4,000 PSI without rupture based on burst test

Application:

For use in braking system of the vehicle.

Technical Specification: www.qdgybrakehose.com

Test Items
Test Condition
Standard
Test Results
ID
Normal
3.2mm
3.15~3.45mm
OD
Normal
10.5mm
10.30~10.70mm
Expansion
1000psi
0.33cc/ft max.
0.14~0.16cc/ft
1500psi
0.42cc/ft max.
0.20~0.22cc/ft
2900psi
0.61cc/ft max.
0.41~0.43cc/ft
Burst

4000psi×2min;pressure rated 25,000±10,000psi/min
>7000psi No seepage
>10,500psi
Whip
235~250psi
>35h
>70h
Tensile
tensile speed:218±3mm/min
>1446N
2400N
Cold Bend
-45°C ~-48°C× 72h, 3-5s,bending180°
No cracking
No cracking
Ozone
100pphm×70h×40°C, 7X
No cracking
No cracking
Impulse
146°C 1±0.1min at 1600psi+70
>7000psi No crack
>7500psi
Compatibility
120°C × 70h
>7000psi No seepage
>8800psi
Salt Spray
5%NaCl, 24h,water cleanout in 35°C
