Flange to Flange Heavy Duty Compression Load Cell 5t, 10t, 20t, 30t, 50t-CF-811

Product Description:

The CF-811 is a strain gauge force sensor designed for compression application, covering a capacity range from 5t to 50t. The CF-811 features flange ends on both side with through-hole design. Rugged stainless steel construction and reliable strain gage technology make this unit popular for a variety of industrial applications such as punching euipment, impact testing euipment, pneumatic hydraulic euipment etc. The CF-811 is provided with 4 wiring within a braided shielded cable(overall cable length 7m).

Brans are always devoted to delivering satisfied and favourable services to each our clients to meet their specific needs. We deeply understand that each apllication is different and requires a customized response.

To make sure providing the best solution, the load cell can be adapted to meet customer requirements.

Features&Applications:

• Heavy duty flange type compression force sensor
• Stainless steel construction
• Capacity: 5t, 10t, 20t, 30t, 50t
• Different cable lengths,capcities, dimensions and other options available
• Mainly used for punching equipment, impact testing euipment, pneumatic hydraulic euipment

Specifications:

Dimension(MM):

Load Direction:

Wiring:

Load Cell Packaging and Shipping

To ensure safe arrival at your location, the load cell will be carefully packaged and shipped. The packing process is as follows:

1. The load cell will be placed in a sturdy cardboard box to protect it from external damage during shipping.
2. The box will be filled with foam padding to provide additional cushioning and prevent the load cell from moving during shipping.
3. The load cell will be sealed in a plastic bag to protect it from moisture and other environmental factors.
4. Additional layers of bubble wrap will be provided for additional protection.
5. The carton is securely taped to prevent tampering.
6. A shipping label with your address and product information is attached to the box.
7. The package is shipped using a reliable and trusted freight carrier.

Once the package is shipped, you will receive a tracking number to monitor the status of your delivery. Please ensure that someone is available at the delivery address to receive the package to avoid any delays or problems.
