• High Gravity Mash Tun
  • Low pressure steam jacket with PLC controlled temperature control for optimum profile capability
  • VFD speed and function controlled, custom engineering mash mixer for low sheer, efficient mash mixing designed to handle high gravity brews

• High Gravity Lauter Tun designed to handle larger grist loads
  • Integrated, VFD speed and function controlled rake system designed to cut and lift grain bed to maximize extract yield, reduce lautering time and automate grain out processes
  • Custom designed wedge wire false bottom designed to maximize yield and minimize grain pass-through
  • Grain out access manway for easy and efficient grain out processing
  • Multipoint wort collection design for uniform bed formation and high yield extract collection

• Brew Kettle with integrated steam jacket and temperature control
  • Custom designed vessel optimized for rapid boiling and DMS removal improving product quality and energy efficiency
  • Low pressure steam jacket with PLC controlled temperature control for efficient and vigorous boil control

• Whirlpool Vessel for efficient and optimal trub separation
  • Tangential inlet for high centrifugal circulation of wort and trub separation
  • Whirlpool vessel designed to maximize wort yield with sloping bottom

Standard Features and Output

• All parts of the equipment are made of high quality stainless steel SUS304 with Argon welding (TIG Welding );
• Insulation : PU;
• Lauter tun configures combi-grain raking device and milling sieve plate ;
• Mash kettle tun is with stirrer device ;
• Electronic thermometer sensors ;
• Sparying ball ;
• Heating with dimple jacket (or electric heating )and stirrer device ensures temperature rise rate and improve overall system efficiency with avoiding coking;
• The tangent whirlpoor design accords with the heat concretion subsidence characteristics ;
• PLC design of control program meet demands of various process of craft beer ;
• Options : Automatic grain removing device , (frequency converting control ) bottom door of grain removal .
