500L Brewing Equipment Stainless Steel Fermentation Tank Steam Jacket Brew Kettle
500L Brewing Equipment Stainless Steel Fermentation Tank Steam Jacket Brew Kettle
500L Brewing Equipment Stainless Steel Fermentation Tank Steam Jacket Brew Kettle
500L Brewing Equipment Stainless Steel Fermentation Tank Steam Jacket Brew Kettle
500L Brewing Equipment Stainless Steel Fermentation Tank Steam Jacket Brew Kettle
500L Brewing Equipment Stainless Steel Fermentation Tank Steam Jacket Brew Kettle
Specifications
Brand Name :
YDL
Model Number :
YDL
Certification :
ISO , CE
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
100 Sets / Month
Delivery Time :
Within 30 - 60 Days
Packaging Details :
With plastic foam firstly and then outside by wooden cases(standard export packaging)
Material :
Stainless Steel 304 / 316
Color :
Mirror Polish / Steel
Thickness :
3mm for Interior Shell/2mm for Exterior Shell
Heating Method :
Gas, Electric and Steam
Type :
Jacket Brew Kettle
Capacity :
500L
Description


500L Stainless Steel Fermentation Tank Steam Jacket Brew Kettle 2 Vessel Brewhouse

Features
1) Automatic /semi-automatic operation system ,need one or two brewer operate
2) with our equipment you can make different kinds beer such as ale,lager, IPA, stout beer and so on
3) we have different capacity from 50L to 10000L per batch , our brewery equipment approved Pessure CE, ISO ,ROHS,TUV certificate
4) have good feedback from our clients
5) Installation/Operation/ Service/ Maintenance Manual: Provided In English.

We have more kinds Beer Brewing Equipment in different use,
Please contact us,
So we can help you select the right system to meet your needs and fit your budget!


Restaurant micro brewery produced by us is a set of technological equipment for the production of "live" and filtered beer.Brew master make their beer attractive to consumers by unique brewing process and distinctive beer taste.
If desired, they can be placed directly in places of consumption of beer: restaurants, pub, bars, hotels, tourist and shopping centers.
Interpreter may be faced with polished brass, copper besides stainless steel. Also, the microbrewery is placed behind a glass partition that allows visitors to observe the process of making beer. This is an excellent design solution interior anda powerful marketing tool.
Most installation in restaurants, bars and hotels used microbrewery with a capacity from 50 to 1000L.
A network of restaurants uses equipment with higher capacity.

15BBL Beer Brewery
Item Model Specification
Grinding System 300kg-500kg/h Malt Mill Machine Material: Carbon steel or Stainless steel
Roller Material: alloy
This machine can remove the iron and dust automatically
Brewhouse 15BBL 3 Vessels OR 15BBL 2 Vessels + HLT Main equipment: Mashing tun, lauter tun, kettle&whirlpool tank; OR lauter tun, kettle&whirlpool tank, HLT
Inner layer material SUS304, thickness: 3.0mm
External Jacket material: SUS304, thickness: 2.0mm
The inner surface polishing precision: Ra0.4um
Heating way: Steam heating, electric heating, direct fire heating
Tangential whirlpool inlet
Equipped with hops back
100% Stainless Steel suspension type Plate Heat Exchanger
Includes pump, pipeline, heat exchanger, valve, raker, platform, and all other accessories
Optional: Cold liquid tank (CLT)
Fermentation system 15BBL OR 30BBL Fermentation Tank & Bright Beer Tank. You decide quantity Inner layer material SUS304, thickness: 3.0mm
External Jacket material: SUS304, thickness: 2.0mm
The inner surface polishing precision: Ra0.4um
Cone bottom: 60°
Design pressure 0.3MPa; Working pressure 0.15Mpa
Manhole: Top or Side manhole
Cooling way: Dimple Jacket
Equip with Carbonated Port, Dry Hops Port, Sample Valve, Pressure Release Valve, Pressure Gauge, Racking Arm
Includes pipeline, yeast adding tank, valve, and all other accessories
Cooling System 45BBL Glycol Tank & 15HP-20HP Chiller Chiller compressor is USA Copeland
Inner layer material SUS304, thickness: 3.0mm
External Jacket material: SUS304, thickness: 2.0mm
The inner surface polishing precision: Ra0.4um
Pump is Stainless Steel Model
Cooling media: glycol water or alcohol water
Includes pipeline, valve, and all other accessories
Glycol tank can be 30BBL if you choose cold liquid tank
CIP system 200L CIP Trolley Main equipment: NaOH tank, H2O2 tank;
Equip with control cabinet
Centrifugal pump
Control System PID Cabinet OR PLC Cabinet Material: Carbon Steel OR Stainless Steel
Component has CE certificate
Optional: UL Certificate, Siemens component, Omron component
Others Filling System, Capping System, Filtering System, Water Treatment System, Pasteurizer and so on



500L Brewing Equipment Stainless Steel Fermentation Tank Steam Jacket Brew Kettle500L Brewing Equipment Stainless Steel Fermentation Tank Steam Jacket Brew Kettle
