Mirror Polish Stainless Steel Conical Fermenter Mini Beer Or Wine Making
Mirror Polish Stainless Steel Conical Fermenter Mini Beer Or Wine Making
Mirror Polish Stainless Steel Conical Fermenter Mini Beer Or Wine Making
Mirror Polish Stainless Steel Conical Fermenter Mini Beer Or Wine Making
Specifications
Brand Name :
YDL
Model Number :
YDL
Certification :
ISO , CE
Place of Origin :
China
MOQ :
1 Set
Price :
Negotiation
Payment Terms :
L/C, T/T
Supply Ability :
100 Sets / Month
Delivery Time :
Within 30 - 60 Days
Packaging Details :
With plastic foam firstly and then outside by wooden cases(standard export packaging)
Material :
Stainless Steel 304 / 316L
Color :
Mirror Polish
Thickness :
3mm for Interior Shell/2mm for Exterior Shell
Type :
Mini
Application :
Beer or Wine
Name :
Conical Beer Fermenter
Description

1. Name of commodity

Stainless Steel Mini Beer or Wine Making Conical Beer Fermenter

2. Application

Restaurant, hotel, brewpub, bar, university laboratory, microbrewery

3. Main machine

Description of goods Mash kettle boiler & lauter/whirlpool tun
Capacity 1000L
Main machine A mixing device, A motor(0.75KW)with reducer
Raw material Stainless steel& Red copper(Inner polishing up to 0.4 Micron)
Thickness liner: 3mm; external biliary:2.5mm
Insulation material Thickness of insulation material polyurethane: δ100mm
Volume Gross Volume1250L,EfficiencyVolume: 1000L
Cleaning system With CIP wash rotating ball
Thermometer Digital Temperature Thermometer
Heating method Steam heating

YDL can supply wine tank ,storage tank, beer tank,wine tank,fermenter,water tank,juice tank,and pressure vessel

1)Tank (Pressure Vessel) volume: 0.5-5000 cubic meters
2)Dimension: Diameter and height according to the requirements
3)Material: Stainless Steel (304 or 316L)
4)Tank shell thickness: 2mm or more (according to the design or customer required)
5)Pressure (MPa): Atmospheric pressure-Middle pressure (According to the Chinese
Design standard)
6)Function: Storage or fermentation tank
7)Design temperature C-degree: -5-80
8)Medium: Various drinks including wine, beer, fruit wine, fruit juice and so on.
9)Tank surface: The original surface of the stainless steel plate (or polishing if required)
10)Operation plate form: We can design the plate form if required.
11)Mixing: Top side or bottom mixing.
12)General accessories(If required): Manhole, CIP, respirator, sight glass, mixing
13)Manufacture standard: Chinese Pressure Vessel Design and Making Standard
14)Guarantees inner quality and safety, good looking appearance and function by introducing international advanced large-sized equipment of pulse plasma arcwelder and auto polishing machines and cooperating with international famous finished
How to choose
Bright Tank Series Volume by US Gallon Conical Degree Diameter Height
2HL Bright Tank 53US Gallon 60 (70,90 availabe) 820mm 1400mm
3HL Bright Tank 79US Gallon 60 (70,90 availabe) 860mm 1650mm
6HL Bright Tank 106US Gallon 60 (70,90 availabe) 1060mm 1900mm
8HL Bright Tank 132US Gallon 60 (70,90 availabe) 1160mm 2050mm
10HL Bright Tank 159US Gallon 60 (70,90 availabe) 1260mm 2100mm
12HL Bright Tank 211US Gallon 60 (70,90 availabe) 1360mm 2100mm
15HL Bright Tank 264US Gallon 60 (70,90 availabe) 1360mm 2400mm
20H Bright Tank 317US Gallon 60 (70,90 availabe) 1560mm 2350mm
25HL Bright Tank 396US Gallon 60 (70,90 availabe) 1560mm 2800mm
30HL Bright Tank 528US Gallon 60 (70,90 availabe) 1760mm 2700mm
35HL Bright Tank 660US Gallon 60 (70,90 availabe) 1760mm 3050mm
40HL Bright Tank 793US Gallon 60 (70,90 availabe) 1760mm 3350mm
50HL Bright Tank 925US Gallon 60 (70,90 availabe) 1760mm 3900mm
60HL Bright Tank 1057US Gallon 60 (70,90 availabe) 1960mm 3860mm
70HL Bright Tank 1321US Gallon 60 (70,90 availabe) 1960 mm 4260mm
100HL Bright Tank 1585US Gallon 60 (70,90 availabe) 2250mm 4920mm
150HL Bright Tank 1849US Gallon 60 (70,90 availabe) 2250mm 6750mm

Mirror Polish Stainless Steel Conical Fermenter Mini Beer Or Wine MakingMirror Polish Stainless Steel Conical Fermenter Mini Beer Or Wine MakingMirror Polish Stainless Steel Conical Fermenter Mini Beer Or Wine MakingMirror Polish Stainless Steel Conical Fermenter Mini Beer Or Wine Making
