P110 Casing Pipes with TPCQ thread
P110 Casing Pipes with TPCQ thread
Specifications
Place of Origin :
China
Brand Name :
Huibo
Certification :
API 5CT
MOQ :
25MT
Price :
FOB, CIF, CFR
Packaging Details :
in bundles with steel strips
Delivery Time :
10-15days
Payment Terms :
TT/LC
Supply Ability :
6000MT/Month
Description

TUBING PIPES
STANDARD: API SPEC 5CT
Outside Diameter Specified(mm) Nominal Weight Threads & Coupling Steel Grade Wall Thickness (mm) Type of Thread
Ib/ft N U E U
60.32(2 3/8") 4.70 H,J,L,P 4.83 YES YES
5.80 C,N,L,P 6.45 YES YES
5.95 L,P 6.45 YES YES
7.35 C,L 8.53 YES
7.45 L,P 8.53 YES
73.02(2 7/8") 6.40 H,C,N,L,P 5.51 YES
6.50 H,C,N,L,P 5.51 YES
7.80 C,N,L,P 7.01 YES
7.90 C,N,L,P 7.01 YES
8.60 C,N,L,P 7.82 YES
8.70 C,N,L,P 7.82 YES
9.45 L,C 8.64 YES
88.90(3 1/2") 9.20 H,J,C,N,L,P 6.45 YES
9.30 H,J,C,N,L,P 6.45 YES
10.20 H,J,C,N,L 7.34 YES
12.70 C,N,L,P 9.52 YES YES
12.95 L,P 9.52 YES
101.60(4") 9.50 H,J,C,N,L 5.74 YES
11.00 H,J,C,N,L 6.65 YES
114.30(4 1/2") 12.60 H,J,L,N,C,T 12.75 YES
12.75 H,J,L,N,C,T 12.75 YES
CASING PIPES
STANDARD: API SPEC 5CT
Outside Diameter Specified(mm) Nominal Weight Threads & Coupling Steel Grade Wall Thickness (mm) Type of Thread
Ib/ft Short Long Buttress TG-QMI
114.30(4 1/2") 9.50 H,J,K 5.21 YES
10.50 J,K 5.69 YES YES
11.60 J,K,C,L,N,P 6.35 YES YES YES
13.50 C,L,N,P 7.37 YES YES
15.10 P,Q 8.56 YES YES
127.00(5") 11.50 J,K 5.59 YES
13.00 J,K 6.43 YES YES YES
15.00 J,K,C,L,N,P 7.52 YES YES YES
18.00 C,L,N,P,Q 9.19 YES YES
21.40 C,L,N,P,Q 11.10 YES YES
23.20 C,L,N,P,Q 12.14 YES YES
24.10 C,L,N,P,Q 12.70 YES YES
139.70(5 1/2") 14.00 H,J,K 6.20 YES
15.50 J,K 6.98 YES YES YES YES
17.00 J,K,C,L,N,P 7.72 YES YES YES YES
20.00 C,L,N,P 9.17 YES YES YES
23.00 C,L,N,P,Q 10.54 YES YES YES
168.28(6 5/8") 20.00 H,J,K 7.32 YES YES YES
24.00 J,K,C,L,N,P 8.94 YES YES YES
28.00 C,L,N,P 10.59 YES YES
32.00 C,L,N,P,Q 12.06 YES YES
177.80(7") 20.00 H,J,K 6.91 YES
23.00 J,K,C,L,N 8.05 YES YES YES YES
26.00 J,K,C,L,N,P 9.19 YES YES YES YES
29.00 C,L,N,P 10.36 YES YES YES
32.00 C,L,N,P 11.51 YES YES YES
35.00 C,L,N,P,Q 12.65 YES YES YES
38.00 C,L,N,P,Q 13.72 YES YES YES
193.68(7 5/8") 24.00 H 7.62 YES
26.40 J,K,C,L,N 8.33 YES YES YES
29.70 C,L,N,P 9.52 YES YES
33.70 C,L,N,P 10.92 YES YES
39.00 C,L,N,P,Q 12.70 YES YES
42.80 C,L,N,P,Q 14.27 YES YES
45.30 C,L,N,P,Q 15.11 YES YES
47.10 C,L,N,P,Q 15.88 YES YES
196.85(7 3/4") 46.10 C,L,N,P,Q 15.11
219.08(8 5/8") 24.00 J,K 6.71 YES
28.00 H 7.72 YES
32.00 H,J,K 8.94 YES YES YES
36.00 J,K,C,L,N 10.16 YES YES YES
40.00 C,L,N,P 11.43 YES YES
44.00 C,L,N,P 12.70 YES YES
49.00 C,L,N,P,Q 14.15 YES YES
244.48(9 5/8") 32.30 H 7.92 YES
36.00 H,J,K 8.94 YES YES YES YES
40.00 J,K,C,L,N 10.03 YES YES YES
43.50 C,L,N,P 11.05 YES YES YES
47.00 C,L,N,P,Q 11.99 YES YES YES
53.50 C,L,N,P,Q 13.84 YES YES YES
273.05(10 3/4") 32.75 H 7.09 YES
40.50 H,J,K 8.89 YES YES
45.50 J,K 10.16 YES YES
51.00 J,K,C,L,N,P 11.43 YES YES
55.50 C,L,N,P 12.57 YES YES
60.70 P,Q 13.84 YES YES
65.70 P,Q 15.11 YES YES
298.45(11 3/4") 42.00 H 8.46 YES
47.00 J,K,M 9.53 YES YES
54.00 J,K,M 11.05 YES YES
60.00 J,K,M,L,N,C,P,Q 12.42 YES YES
339.7(13 3/8") 48.00 H 8.38 YES
54.50 J,K 9.65 YES YES
61.00 J,K 10.92 YES YES
68.00 J,K,C,L,N,P 12.19 YES YES
72.00 C,L,N,P,Q 13.06 YES YES
406.40(16") 65.00 H 9.53 YES
75.00 J,K,M 11.13 YES YES
84.00 J,K,M 12.57 YES YES
473.08(18 5/8") 87.50 H,J,K,M 11.05 YES YES YES
508.00(20") 94.00 H,J,K 11.13 YES YES YES
106.50 J,K 12.70 YES YES YES
133.00 J,K 16.13 YES YES YES
