15W 0.9kg Diameter 60mm Brushless DC Gear Motor
15W 0.9kg Diameter 60mm Brushless DC Gear Motor
15W 0.9kg Diameter 60mm Brushless DC Gear Motor
15W 0.9kg Diameter 60mm Brushless DC Gear Motor
15W 0.9kg Diameter 60mm Brushless DC Gear Motor
15W 0.9kg Diameter 60mm Brushless DC Gear Motor
15W 0.9kg Diameter 60mm Brushless DC Gear Motor
15W 0.9kg Diameter 60mm Brushless DC Gear Motor
Specifications
Place of Origin :
China
Brand Name :
OEM
Certification :
CE/ISO/ROHS
Supply Ability :
25000pc/month
Packaging Details :
with export carton
MOQ :
Negotiable
Price :
Negotiable
Delivery Time :
15-25days
Payment Terms :
L/C, T/T, Western Union, Paypal
Usage :
Boat, Car, Electric Bicycle, Fan, Home Appliance, Water Pump
Type :
Gear Motor
Speed(RPM) :
3000r/min
Continuous Current(A) :
≤2.0
Efficiency :
IE 2
Color :
black
Rated Speed :
3000 r/min
Material :
metal
Weight :
0.9kg
Noise :
low
Power :
15W
Diameter :
60mm
Description

15W 0.9kg Diameter 60mm Brushless DC Gear Motor

15W 60mm Motors
Model Voltage Power No-load Parameters Load Parameters Brush Life Motor Weight
Speed Current Speed Torque Current
V W r/min A r/min mN.m A H kg
L2D15-12 12 15 3200 0.8Max 2950 48 2 2000 0.9
L2DW15-12 12 15 3200 0.8Max 2950 48 2 2000 0.9
L2D15-24 24 15 3300 0.4Max 3000 48 1 2000 0.9
L2DW15-24 24 15 3300 0.4Max 3000 48 1 2000 0.9
L2D15-90 90 15 3200 0.2Max 3000 48 0.4 2000 0.9
L2DW15-90 90 15 3200 0.2Max 3000 48 0.4 2000 0.9

1. Motor voltage,power and speed will be customized according to his requestment under the allowed circumstance of adoptable dimension
2. We use W after D in the model to express the external brush motor,such as L2DW06-12GN. If no W, it means the standard internal brush motor. For external brush motor,you can replace the brush directly.For internal ones,we need to disassembly the motor first.
Dimensions
Below are some important dimensions for the 12V Sea Scooter underwater thruster Inrunner Waterproof Brushless Motor .if you want to make some small chnages on some part of them,please contact me. I will offer you a good idea and choice.
15W 0.9kg Diameter 60mm Brushless DC Gear Motor

Lead Wirng Type

Weight: Motor:0.9kg Gearhead: 0.4kg
Mounting screws are included with gearhead.
15W 0.9kg Diameter 60mm Brushless DC Gear Motor

Shaft Section Of Round Shaft Type

Excluding weight and the shaft section motor shape are the same as those of the pinion shaft type.
15W 0.9kg Diameter 60mm Brushless DC Gear Motor

Wiring Diagrm Of Motor

Stanclard length of lead wire:300mm±10,model:UI1015;type:AWG20;lead wire length,model will be customized by client requestment
under allowed circumstance of adoptable dimension.
Common motors parameters range we can offer
Voltage 12V~220V
Current 0.8A~16.0A
Power 6W~750W
Gear Ratio 3~200
Diameters 60mm~104mm
Torque 19mN.m~796mN.m
This form cannot contain all products from our company. If you want other kinds motors you can send me your requirements. We will offer you the best answer.
Product Application
These Sea Scooter underwater thruster Inrunner Waterproof Brushless Motor . Belod picture shows some of them,including building lobby,stadium,factory,mall/surpermarket,club, amusement park,metro part and so on.
