310VDC Mini High Speed Brushless Motor Customizable 80% Efficiency
310VDC Mini High Speed Brushless Motor Customizable 80% Efficiency
310VDC Mini High Speed Brushless Motor Customizable 80% Efficiency
310VDC Mini High Speed Brushless Motor Customizable 80% Efficiency
310VDC Mini High Speed Brushless Motor Customizable 80% Efficiency
310VDC Mini High Speed Brushless Motor Customizable 80% Efficiency
310VDC Mini High Speed Brushless Motor Customizable 80% Efficiency
310VDC Mini High Speed Brushless Motor Customizable 80% Efficiency
Specifications
Model Number :
Industrial BLDC29-AC220V
Place of Origin :
China
Dimension :
φ29.2*46.5
Bearing At Output :
Ball Bearing
Voltage :
310VDC
Motor Specifications :
Can Be Customized
Name :
High Speed Brushless Motor
Torque :
0.0083NM
Motor efficiency :
80%
Motor Type :
BLDC29-AC220V
Description

High Speed Brushless Motor Customizable 80% Efficiency ≈57.3g Weight

Product Description:

Our high speed brushless motor is an efficient and reliable mini brushless motor designed . With a continuous current of 0.6A, the motor has a power of 130W and a torque of 0.0083NM. The motor is high speed, as it can reach speeds of up to 115000rpm.

Features:

  • Product Name: High Speed Brushless Motor
  • Shaft: 3mm
  • Bearing At Output: Ball Bearing
  • Weight: ≈57.3g
  • Motor efficiency: 80%
  • Dimension: φ29.2*46.5
  • Features:
    • Brushless Electric Motor
    • Mini Brushless Motor
    • High Speed Brushless Motor

Technical Parameters:

Parameter Value
Motor Type BLDC29-AC220V
Shaft 3mm
Name High Speed Brushless Motor
Motor Specifications Can Be Customized
Dimension φ29.2*46.5
Speed 115000rpm
Weight ≈57.3g
Torque 0.0083NM
Continuous current 0.6A
Voltage 310VDC

Applications:

BLDC Motor is a type of motor with a range of exciting features, such as high efficiency, strong controllability, and a lengthy lifespan.It is main used in hairdryer based beauty power tools.

Customization:

High Speed Brushless Motor
  • Model Number: BLDC29-AC220V
  • Place of Origin: China
  • Bearing At Output: Ball Bearing
  • Dimension: φ29.2*46.5
  • Continuous current: 0.6A
  • Voltage: 310VDC
  • Shaft: 3mm

Our High Speed Brushless Motor offers superior performance and efficiency compared to traditional brushless electric motor. The motor features a Model Number: BLDC29-AC220V, Place of Origin: China, Bearing At Output: Ball Bearing, Dimension: φ29.2*46.5, Continuous current: 0.6A, Voltage: 310VDC and Shaft: 3mm. It is the perfect choice for those seeking reliable and high-speed brushless electric motor.

Support and Services:

High Speed Brushless Motor Technical Support & Service

Our technical support and service is available for High Speed Brushless Motor products. Our experienced product specialists are available to provide support and answer any questions you may have.

  • Technical support for installation and operation
  • Troubleshooting and diagnosis
  • Repair and maintenance
  • Product training and education

We pride ourselves on providing exceptional customer service and look forward to helping you find the best solution for your needs. Please contact us for more information.
