Pendant remote control single beam 10 ton overhead crane widely used
Pendant remote control single beam 10 ton overhead crane widely used
Pendant remote control single beam 10 ton overhead crane widely used
Pendant remote control single beam 10 ton overhead crane widely used
Specifications
Brand Name :
Bestaro
Model Number :
LD
Certification :
ISO, CE
Place of Origin :
Xinxiang, China
MOQ :
1 set
Price :
Negotiable
Payment Terms :
L/C, D/P, T/T
Supply Ability :
1000 sets/month
Delivery Time :
15 days
Packaging Details :
Electric parts are packed by high quality wooden box, Main beams, end beams and electric hoist are packed by plastic woven cloth
Origin of place :
China
Color :
Red, Yellow or Customized
Capacity :
0.5- 20 ton
Warranty :
2 years
Description

Pendant remote control single beam 10 ton overhead crane widely used

A brief introduction

Single girder overhead crane with the best price is an underslung type crane, it travels suspended under the I beam, it mainly consists of main girder, end carriage, electric hoist, electric system. it is the most popular and pragmatic kind of light lifting crane.
It is applicable to transfer assembly, check and repair as well as load and unload various materials. Its catching types of equipment are the hook grab or electromagnet.

Pendant remote control single beam 10 ton overhead crane widely used

01-Single girder overhead crane structure

Electric overhead crane Box girder LE Model mainly composed of metal structure (main girder, end truck), electric hoist trolley (lifting mechanism), traveling mechanism and electrical equipment.

1. Reasonable structure, light dead weight

2. Favorable performance, accurate and smooth lifting

3. Safe and reliable traveling

4. Low noise, easy operation

02-single girder overhead crane specification

Capacity 0.5- 20 ton
Span 3.5-31.5 m
Working duty A3-A5
Lifting height 6m 9m 12m 18m 24m 30m or customized
Power supply 3 phase 380v 50 Hz

03-single girder overhead crane application

1. Hydropower Station (A3) is used to repair turbines, etc.

2. Steel mill (A5-A7) lifting steel bags, waste-absorbing, ingots, etc., maintenance

3. Petrochemical (explosion-proof)

4. Warehouse (A3-A5)

5. Power Plant

6. Port, Building

7. General Processing and Manufacturing Workshop (A3-A5)

04-Crane parts

Pendant remote control single beam 10 ton overhead crane widely used

05-The production process

Pendant remote control single beam 10 ton overhead crane widely used

06-single girder overhead crane package

1. Electric parts are packed by high-quality plywood crate, to reduce distortion in conveying.

2. Main beams, end beams are packed by plastic woven cloth, to reduce abrasion when transport

3. The whole set of overhead cranes will be shipped by container or by bulk.

Pendant remote control single beam 10 ton overhead crane widely used
