Hot Dip Galvanized Steel Ground Anchors / Soil Screw Anchors For Small Windmills
Hot Dip Galvanized Steel Ground Anchors / Soil Screw Anchors For Small Windmills
Hot Dip Galvanized Steel Ground Anchors / Soil Screw Anchors For Small Windmills
Hot Dip Galvanized Steel Ground Anchors / Soil Screw Anchors For Small Windmills
Hot Dip Galvanized Steel Ground Anchors / Soil Screw Anchors For Small Windmills
Hot Dip Galvanized Steel Ground Anchors / Soil Screw Anchors For Small Windmills
Specifications
Brand Name :
NTS
Model Number :
NTS28
Certification :
ISO9001 CE
Place of Origin :
China
MOQ :
200 pcs
Price :
as discussed
Supply Ability :
50000 pcs per month
Delivery Time :
30 days
Packaging Details :
150pcs/pallet
Material :
Q235
Surface :
hot dip galvanized ,red painted
Rod size :
1" 1 1/4"
Length :
54" 66" 96"
Helix :
6" 8" 10"
Helix thickness :
6mm
Eye shape :
forged triple eye
Description

Galvanized Forged Steel Ground Anchor Helix Ground Anchor For Earth Ground Anchor

Product Information

1. Heavy Duty 1 1/4″ x 66” with 10” Helix “Galvanized” Screw Anchor Heavy duty 1 1/4″ Shaft and Formed Triple closed Eye

Ideal for corrosive environments in medium to soft Soils – “Hot dipped Galvanized Finish”

2. ground anchor is Commonly used for Mooring Boats and docks, securing vineyard trellises, Large storage
sheds, retaining walls, radio antennas,small windmills, Long Hop runs


3. helix ground anchor Holding strength is based on clay soils which are of hard to medium density. The holding strength is reduced in softer less dense soils and sandy soils.

4. To ensure maximum holding strength, anchor must be installed to full depth with the bottom of eyelet at ground level.

5. Can be installed by hand in softer soils with a “installation bar” harder soils may need power installation equipment

12,000 lb+ pull out resistance in Hard Pan soils- less in less dense soils

Specifications:

Finish: Hot Dip Galvanized

Shaft Diameter: 11/4″

Helix: Single 10″

ID of Eye: 1 1/2″ Forged

Length: 66″ 96"


Earth Screw Helix Anchor dimension and catalogue:

CODE SIZE ROD DIA LENGTH HELIX TENSILE STRENGTH
NTS-1513 1" 25mm 54" 6" 9000lbs
NTS-1514 1" 25mm 66" 8" 9000lbs
NTS-1515 1" 25mm 72" 10" 10000lbs
NTS-1516 1" 25mm 96" 10" 10000lbs
NTS-1517 1 1/4" 31.7mm 66" 8" 9000lbs
NTS-1518 1 1/4" 31.7mm 72" 10" 10000lbs
NTS-1519 1 1/4" 31.7mm 96" 10" 10000lbs
NTS-1520 1 1/4" 31.7mm 96" 12" 11000lbs

Hot Dip Galvanized Steel Ground Anchors / Soil Screw Anchors For Small Windmills

Customizing is welcome!


Here are the pictures of the helix earth screw anchor

Hot Dip Galvanized Steel Ground Anchors / Soil Screw Anchors For Small Windmills

Other types of helix pipe anchor:

Hot Dip Galvanized Steel Ground Anchors / Soil Screw Anchors For Small Windmills
Packing pictures of ground anchor: packing size and quantity depends on the rod and plate diameter

Hot Dip Galvanized Steel Ground Anchors / Soil Screw Anchors For Small Windmills

Our company Testing :
Hot Dip Galvanized Steel Ground Anchors / Soil Screw Anchors For Small Windmills
