Commercial Standard Rigging Hardware , Jis Type Screw Pin Chain Shackle
Commercial Standard Rigging Hardware , Jis Type Screw Pin Chain Shackle
Commercial Standard Rigging Hardware , Jis Type Screw Pin Chain Shackle
Commercial Standard Rigging Hardware , Jis Type Screw Pin Chain Shackle
Commercial Standard Rigging Hardware , Jis Type Screw Pin Chain Shackle
Commercial Standard Rigging Hardware , Jis Type Screw Pin Chain Shackle
Commercial Standard Rigging Hardware , Jis Type Screw Pin Chain Shackle
Commercial Standard Rigging Hardware , Jis Type Screw Pin Chain Shackle
Specifications
Brand Name :
NTS
Model Number :
NTS95
Certification :
ISO9001 CE
Place of Origin :
China
MOQ :
2000pcs
Price :
as discussed
Supply Ability :
10000 per month
Delivery Time :
35 days
Packaging Details :
boxes ,100pcs/box with a plastic bag
Material :
Q235
Surface :
zinc plated,plain
Size :
6mm 8mm10mm 12mm 14mm 16mm
Process :
Forged
Type :
Hook-Hook ,Hook-Eye ,Eye-eye
Pin type :
Screw pin round pin
Description

JIS commercial standard shackle Jis Type Screw Pin Chain Shackle

zinc plated commercial type large dee shackle screw pin shackle for rigging hardware

Rigging carbon steel JIS D Type Shackles

1. Standard:EUROPEAN TYPE,JIS TYPE,US. TYPE,DIN TYPE

2. Material:Stainless steel 304 or 316,Carbon Steel,Alloy,

3. Surface:Hot dipped galvanized,Electro galvanized,Self-colored

4. Colours of Pin:Red/Yellow/Other colours

5. Packing:Put in PP bags then in steel pallet or special request from Customers

6. Delivery Time:Within 20 days

We are a manufacturer of rigging hardware. We produce Shackle, Turnbuckle,

Load binder, Hook, Wire rope clip, Eye Bolt and Nut, Thimble, Connecting Link,

Snap hook etc.

Any questions , pls free to contactwith us , reply will be sent as soon aspossible .

jis trawling shackle

1. OEM manufacture.

2. Precision : according to your drawings.

3. Parts are used on vehicles, parachute cord,connecting, etc.

4. We are able to supply sheet metal, mechanical parts machining, surface treatment such as anodization and plating according to our customers' requirement.

5. Our products have been exported to American, Canada, England,Belgium and Japan,we can guarantee the high quality.

6. Offer OEM service according to your drawing and samples.

7. Quality assurance: 100% inspection before shipment by micrometre, height gauge, projector measuring machine, coordinate measuring machine(CMM).

Advantages:

1. Fast lead time

2. Small MOQ available

3. Non-standard/standard/OEM/ODM/customized service provided

4. Certificate:ISO9001:2008, RoHS,SGS
5. High precision

SWL D d a c b Approx 100 pcs/WT
kg mm mm mm mm mm kg
80 5 5 10 19 11 1.9
100 6 6 13 25 14 3.4
200 8 8 16 32 18 7
320 10 10 19 38 20 13
520 12 12 25 51 26 26
800 16 16 32 64 33 50
1100 20 20 38 76 40 80
1500 22 22 44 89 50 130
2100 25 25 51 100 57 200
3000 28 28 57 115 68 310
3500 32 32 64 127 73 430
5000 38 38 76 152 85 700
7000 45 45 90 180 96 1250
8000 50 50 102 200 108

1750

Commercial Standard Rigging Hardware , Jis Type Screw Pin Chain Shackle

ROUND PIN SCREW PIN SHACKLE FOR JAPAN

Commercial Standard Rigging Hardware , Jis Type Screw Pin Chain Shackle Commercial Standard Rigging Hardware , Jis Type Screw Pin Chain Shackle

Commercial Standard Rigging Hardware , Jis Type Screw Pin Chain Shackle
