3 Stage Standing on Mast Electric Stacker 1.6ton load mast extender up to 5.5m
3 Stage Standing on Mast Electric Stacker 1.6ton load mast extender up to 5.5m
3 Stage Standing on Mast Electric Stacker 1.6ton load mast extender up to 5.5m
3 Stage Standing on Mast Electric Stacker 1.6ton load mast extender up to 5.5m
Specifications
Brand Name :
KAMUJA
Model Number :
CL1645QD/CL1655QD
Place of Origin :
China
MOQ :
5 UNIT
Payment Terms :
T/T
Supply Ability :
No limited
Delivery Time :
30 DAYS
Price :
USD 4.5K-6K/ UNIT
Packaging Details :
14 UNITS/40HQ
Power souce :
AC Motor
Rated loading capacity :
1600kg / 1.6t
Max. lifting height :
4.5m & 5.5m
Fork width :
570/695 mm
Fork size :
60/180/1150 s/e/l (mm)
Operation :
Standing on
Description

PRODUCT FEATURES

1. All-pointed standard electronic power steering system, help the response very well,the handle manipulation is comfortable,greatly reduces the operator's labor intensity,turning to low speed,high speed,steering more intelligent,more accurate,driving feel more Smooth;
2. High performance battery,cycle performance,and deep discharge recovery ability,superior battery life,long service life is long;
3. Configure the protective arm on both sides of the driving position to protect the operator security;
4. The center of the drive system sets a floating bracket to ensure the stability of the vehicle operation,and the body is smooth and not tilted;
5. The pedal foot feels comfortable,64 pieces of butterfly shrapnel can quickly absorb the vibration generated by the vehicle,alleviate the impact of the road surface;the number of components required for the AC motor is small,and there is no need to replace the loss of regular replacement. Almost no maintenance,more efficient,and more robust.

Characteristics
1.01 Model CL1645QD CL1655QD
1.02 Power unit Electric
1.03 Operation Standing on
1.04 Rated traction weight Q(kg) 1600
1.05 Load centre c(mm 600
1.06 Axle centre to fork face x(mm) 675
1.07 Wheel base y(mm) 1320
1.08 Service weight with battery kg 1260 1340
Wheels/Tyres
2.01 Wheels type PU
2.02 Driving wheel size φ250×75
2.03 Bearing wheel size φ80×70
2.04 additional wheels(dimensions) φ150×58
2.05 Wheels,number front/rear(x=driven) 1,4/2
2.06 Track width 828
2.07 Track width 390/515
Dimensions
3.01 Free lift h1(mm) 2054 2386
3.02 Lift h2(mm) 1561 1894
3.03 Height of mast extender h3(mm) 4500 5500
3.04 Height of seat/stand-on platform h4(mm 5060 6060
3.05 Overall height(With handle) h14(mm 1040/1415
3.06 Lowered fork height h13(mm) 86
3.07 Overall length 11(mm) 2085
3.08 Length to fork face 2 (mm) 925
3.09 Overall width b1/b2(mm) 1060
3.10 Fork dimensions s/e/l
(mm)		 60/180/1150
3.1 Nidth of forks b5(mm) 570/695
3.12 Min.Ground clearance m2(mm 26
3.13 Aisle width with pallet 1000x 1200 across
forks		 Ast (mm) 2503
3.14 Aisle width with pallet 800 x1200 along
forks		 Ast(mm 2480
3.15 Min.Turning radius Wa(mm 1630
Performance
4.01 | Travel speed,laden/unlader (km/h) 5.2/5.5
4.02 Lifting speed,with/without load mm/s) 100/140
4.03 Lowering speed,with/without load mm/s) 75/110
4.04 Maximum climbing ability,with/without
load		 (%) 6/8
4.05 Service brake Electromagnetic
Drive
5.01 Drive motor,60 minute rating (kW) 1.5
5.02 Lift motor rating at S315% (kW) 3.0
5.03 Battery voltage/rated capacity V/Ah) 24/240
5.04 Battery weight (±5%) (kg) 240
Other
6.01 Type of drive contro AC
6.02 Noise level at operator 's ear (dB(A)) ≤70
