24 Ton Luffing Tower Crane 60m Radium Luffing Jib Tower Crane QTD400-24
24 Ton Luffing Tower Crane 60m Radium Luffing Jib Tower Crane QTD400-24
Specifications
Brand Name :
NTP
Model Number :
QTD400-24
Certification :
CE
Place of Origin :
China
MOQ :
1 UNIT
Price :
TBD(USD)
Payment Terms :
T/T
Supply Ability :
No limited
Delivery Time :
30 DAYS
Packaging Details :
Export Package
Model :
QTD400-24
Max. Radium :
60m
Maximum hoisting capacity :
24t
Tip Load :
5.0t
Mast Section :
2.0*2.0*3.0m)
Rated hoisting moment :
2600kN·m
Description

Luffing Tower Crane QTD400-24 Max. Capacity Load 24 ton

FACTORY INTRODUCTION

24 Ton Luffing Tower Crane 60m Radium Luffing Jib Tower Crane QTD400-2424 Ton Luffing Tower Crane 60m Radium Luffing Jib Tower Crane QTD400-24

The manufacture is founded in 1958, is an industry-leading enterprise integrating the R&D, manufacturing, installation, transformation and maintenance of construction hoisting machinery, and also one of the first four manufacturers in China to obtain the manufacture license o construction machinery.

Two production bases in south of China, covering an area of 360,000 square meters and equipped with more than 1,200 sets of advanced processing equipment, with an annual output of over RMB 3 billion.

TYPES

24 Ton Luffing Tower Crane 60m Radium Luffing Jib Tower Crane QTD400-24

Outer cage type tower crane:

The standard sections ofthe tower body can be installed and removed as a whole, making such a tower crane easy to connection and rellable in operation, quick in lifting up and down.

24 Ton Luffing Tower Crane 60m Radium Luffing Jib Tower Crane QTD400-24

Internal climbing type tower crane:

The tower crane is installed inside a building and climbs upward with the help ofthe building structure without any independent foundation, additional attachment devices or standard sections. Such a tower crane features a low cost, a wider construction coverage area and higher work efficiency Furthermore, can be transformed into an attached tower crane at a low cost.

QTD260-16 Luffing Tower Cranes

Drawing of Tower Crane Structure:

24 Ton Luffing Tower Crane 60m Radium Luffing Jib Tower Crane QTD400-24

Tower:

24 Ton Luffing Tower Crane 60m Radium Luffing Jib Tower Crane QTD400-2424 Ton Luffing Tower Crane 60m Radium Luffing Jib Tower Crane QTD400-24

Sectional dimensions of tower

section(m×m×m)

Reinforced

section

 Standard section FSH(m) Max.Height
2.0*2.0*3.0(outer cage) 2 8 43.7 205.7

Load Diagrams

24 Ton Luffing Tower Crane 60m Radium Luffing Jib Tower Crane QTD400-24

Main Technical Parameters

Hoisting performance Rated hoisting moment 4000kN.m
Maximum hoisting capacity 24 t

Mechanism

performance

 2Fall 4Fall Motor
t m/min t m/min
Lifting 12 0~35 24 0~17.5 90Kw
6 0~70 12 0~35
Trolleying 15°~85° 3.5 min 90Kw
Slewing 0~0.75r/min 3*155N.m

※ The technical information may vary by the update policy, the changes will be without prior notice.

Download Brochure:

Express.Brochure.QTD400-24.pdf
