Balcony Apartment Design Stainless Steel Glass Railing Balustrdae Brushed / Mirror
Balcony Apartment Design Stainless Steel Glass Railing Balustrdae Brushed / Mirror
Balcony Apartment Design Stainless Steel Glass Railing Balustrdae Brushed / Mirror
Balcony Apartment Design Stainless Steel Glass Railing Balustrdae Brushed / Mirror
Balcony Apartment Design Stainless Steel Glass Railing Balustrdae Brushed / Mirror
Balcony Apartment Design Stainless Steel Glass Railing Balustrdae Brushed / Mirror
Specifications
Brand Name :
PRIMA
Model Number :
PR-P003
Certification :
CE Certification/ ASNZ 2208
Place of Origin :
CHINA
MOQ :
1 meter
Price :
USD 110-160 meter
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
3000 meters per month
Delivery Time :
35 days
Packaging Details :
Plywood case
Material :
304 / 316 / 316L stainless steel
Shape :
Round / Square / Rectangle Post
Mounted :
Floor-mounted / Face-mounted
Total Height :
1000-1200mm to top of rail
Handrail :
Stainless steel, wood, PVC
Treatment :
Brushed / Mirror
Description

Glass railing balcony apartment design stainless steel post glass balustrade

Summary:

Our Glass Vision system embodies the primary purpose of railings -- safety. Offering the least obstructed view, this frameless glass railing option replaces traditional horizontal rails with small clamps attached to stainless steel posts. Combines simplicity with style & an easy-to-install, durable line that comes in a range of high-quality, attractive design options to customize your look. The mechanically assembled, non-weld, modular railing system allows for a faster, simpler installation without any special training required.

Choose this system for:

1. No horizontal railing to block your sight

2. Reduced shipping costs with no top or bottom rails

3. A choice of glass clamps, either round or square

4. A choice of stainless steel post, round, square, rectangle or flat

5. Top rail offers a usable surface

Advantage:

1. Sleek, clean lines

Provide a sophisticated look to enhance any space

2. Let the light in

With the glass infill system – get great sight lines to maximize light flow for a brighter, more appealing environment

An innovative and modern glass railing system:

Specification:
Maximum Distance 1200mm Post Finishes Satin or Polished
Material Grades Grade 304 (INTERNAL)
Grade 316 / 316L (EXTERNAL)		 Glass Options Coloured, Laminated glass,
Clear glass, Frosted glass


Glass Thickness

 10mm Tempered
12mm Tempered
6+1.52+6mm Laminated


Base Plates
Available

diameter 100mm

100*100mm square

Standard Height
(To top of rail)

914.4mm (36 inches)
1000mm
1067mm(42 inches)
1100mm
1200mm

Compatible
Fixings

 Wood, Metal &
Brick or Concrete

Post & Glass
Measurements

According to the size
(Prices vary)

Post Construction

 Welded base plate
Glass clamps
Tube support to top

Tube Option

Round: 50.8/42.4/38mm
Square: 50*50mm
Rectangle: 50*25mm

Applications

 This system will suit stairs, balconies, pool fence and decking, patio


Balcony Apartment Design Stainless Steel Glass Railing Balustrdae Brushed / MirrorBalcony Apartment Design Stainless Steel Glass Railing Balustrdae Brushed / Mirror
