Modular Industrial Steel Structure Construction Prefab Structural Warehouse Workshop
Modular Industrial Steel Structure Construction Prefab Structural Warehouse Workshop
Modular Industrial Steel Structure Construction Prefab Structural Warehouse Workshop
Modular Industrial Steel Structure Construction Prefab Structural Warehouse Workshop
Modular Industrial Steel Structure Construction Prefab Structural Warehouse Workshop
Modular Industrial Steel Structure Construction Prefab Structural Warehouse Workshop
Modular Industrial Steel Structure Construction Prefab Structural Warehouse Workshop
Modular Industrial Steel Structure Construction Prefab Structural Warehouse Workshop
Specifications
Brand Name :
Lanjing
Model Number :
LJ-Workshop
Place of Origin :
China
MOQ :
1000sqm
Price :
35-55$/sqm
Payment Terms :
TT
Supply Ability :
40,000 Tons per year
Delivery Time :
30-45 days
Packaging Details :
Single Item
Keyword :
Light Frame Steel Construction
Main frame :
Light Steel Q355 Q235
Window :
Aluminum Alloy Window
Door :
Sliding Door, Rolling Door
Wall & Roof :
Sandwich panel; color steel sheet
Secondary Structure :
Purlin; Brace; Knee Brace etc
Cladding :
Steel color sheet
Column & Beam Connection :
High Strength Bolt
Accessories :
Skylight Belt; Ventilator; Downspout;Gutter etc
Drawing Design :
Drawing Design
Color :
Customer's Requirement
Roof Cladding :
Corrugated Steel Sheet/Sandwich Panel
Certifications :
ISO 9001, CE
Sail Finishing :
PVDF/PTFE, Pvc Coated
Crane Capacity :
5Tons*2 Pcs
Structure Type :
Light Steel Structre
Frame :
Weld steel structure frame
material :
steel
Price Term :
FOB CIF CFR EXW
Design Software :
Auto CAD,Teckla
Bracing :
Round Bar/Angle Steel/Steel Rod
Lifespan :
More than 50 years
Downpipe :
UPVC
Life Time :
50 Years
Description

Modular Industrial Steel Structure Construction Prefab Structural Warehouse Workshop


Introduction to Steel Structure Buildings‌

A ‌steel structure building‌ refers to a construction system where the primary load-bearing framework is composed of steel components such as beams, columns, trusses, and joints. These elements are engineered for high ‌strength-to-weight ratios‌ and exceptional ‌plasticity‌, enabling the structure to withstand dynamic loads while maintaining stability‌.


Key Features:
‌1.Material Advantages‌

‌Durability‌: Resistant to corrosion, fire (with coatings), and environmental stresses‌.
‌Lightweight‌: Reduces foundation requirements compared to concrete‌.
‌Recyclability‌: Up to 90% of steel can be reused, minimizing waste and supporting sustainable practices‌.
‌2.Design Flexibility‌

‌Prefabrication‌: Components are manufactured off-site, ensuring precision and accelerating on-site assembly‌.
‌Large-span Capability‌: Ideal for open spaces like stadiums, airports, and industrial warehouses‌.
‌Plastic Design‌: Accounts for material deformation under stress to prevent catastrophic failure‌.‌
3.Modern Innovations
‌Modular Construction‌: Integrates prefabricated steel units for rapid urban development‌.
‌Hybrid Systems‌: Combines steel with materials like glass or composite panels for aesthetic and functional versatility‌.
Steel structures remain a cornerstone of contemporary architecture, balancing efficiency, sustainability, and adaptability‌.


Specification


 Item Materials
Main steel frame column and beam Q235, Q355 steel, paint or galvanization
wind resistant column Q235, Q355 steel, paint or galvanization
Secondary bracing Roof purlin Q235B C/Z section galvanized steel
Wall purlin Q235B C/Z section galvanized steel
Tie bar Q235,φ89*3 round steel pipe
knee brace angle steel,Q235,L50*4
roof horizontal bracing φ20,Q235B steel bar, paint or galvanized
column vertical bracing φ20,Q235B steel bar, paint or galvanized
casing pipe φ32*2.0,Q235 steel pipe
Pulling bar Φ10 round bar Q235
Roof and wall Wall and roof panel corrugated steel sheet/sandwich panel
Protecting system gutter color steel sheet/galvanized steel/stainless steel
Trim and flashing color steel sheet
downspout PVC
self tapping screw
Fastener system Anchor bolts Q235 steel
High strength bolt The Specifications shall be determined according to the design of steel structure.
Normal bolt
Nuts
Window and door Window Aluminium windows
Door According to requirement to choose,can be EPS door,windproof door,high-speed roll-up door,industrial sliding door etc.

Modular Industrial Steel Structure Construction Prefab Structural Warehouse WorkshopModular Industrial Steel Structure Construction Prefab Structural Warehouse WorkshopModular Industrial Steel Structure Construction Prefab Structural Warehouse Workshop
