JIS , DIN Standard Poultry Farm Structure With H Section Column / Beam
JIS , DIN Standard Poultry Farm Structure With H Section Column / Beam
JIS , DIN Standard Poultry Farm Structure With H Section Column / Beam
JIS , DIN Standard Poultry Farm Structure With H Section Column / Beam
JIS , DIN Standard Poultry Farm Structure With H Section Column / Beam
JIS , DIN Standard Poultry Farm Structure With H Section Column / Beam
JIS , DIN Standard Poultry Farm Structure With H Section Column / Beam
JIS , DIN Standard Poultry Farm Structure With H Section Column / Beam
Specifications
Brand Name :
Hongfa
Model Number :
HFP001
Certification :
ISO, BS, AWS
Place of Origin :
CHINA
MOQ :
1ton
Price :
Neogtiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
5000 metric ton per month
Delivery Time :
10 working days
Packaging Details :
By 20GP or 40HQ container
Material Steel Grade :
Q235,Q345,A36,S355
Welding Standard :
GB, AISI, ASTM, JIS, DIN
Main Materials :
H section Steel Columns & Beams
Bracing parts :
C/Z Section steel, round bars
Building size :
Customer's Requirements
Surface treatment :
Galvanized or Anti-rusty paint
Building Type :
Light Steel Structure, Chicken Poultry Farm
Usage :
Chicken or Vegetable Warehouse
Installation :
Engineers Guidance
Accesossories :
Common & High Strength Bolts
Description

Hot Sales Steel Frame With H Section Column & Beam For Poultry Farm Structure

General Description

Poultry Farm Structure use pre-fabricated steel H beams to build the main steel frames and use galvanized C & Z beams as the roof and wall purlin, cladding systerm can do the FRP walls,or use colored steel wall and roof , or can use ASA roof & Wall materaial.

Specification
Items Specification
Main Steel Frame Column Q235, Q345 Welded H Section Steel
Beam Q235, Q345 Welded H Section Steel
Secondary Frame Purlin Q235 C and Z purlin
Knee brace Q235 Angle Steel
Tie Rod Q235 Circular Steel Pipe
Brace Q235 Round Bar
Vertical and Horizontal Support Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance system Roof Panel EPS Sandwich Panel / Glass Fiber Sandwich Panel /
Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet
Wall Panel Sandwich Panel / Corrugated Steel Sheet
Accessories Window Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window
Door Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
Rainspout PVC
Live load on Roof In 120kg/Sqm (Color steel panel surrounded)
Wind Resistance Grade 12 Grades
Earthquake-resistance 8 Grades
Structure Usage Up to 50 years
Temperature Suitable temperature.-50°C~+50°C
Certification ISO9001:2015
Finishing Options Vast array of colors and textures available
Paint Options Alkyd paiting, two primary painting, two finish painting
(gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized.

JIS , DIN Standard Poultry Farm Structure With H Section Column / Beam

Characteristics
1. Wide span: single span or multiple spans, the max span is 36m without middle column
2. Low cost and maintenance: unit price range from USD25/m2 to USD65/m2 according to customers request
3. Fast construction and easy installation: time saving and labor saving
4. Long using lifespan: up to 50 years
5. Nice appearance
6. Others: environmental protection, stable structure, High quake-proof, water proof and fire proof, and energy conserving.

JIS , DIN Standard Poultry Farm Structure With H Section Column / Beam

Quotation Need

Compay Name:
Client 　 Tel/Fax: 　 E-mail: 　
Building Basic Information
Project: 　 Project No.: 　
Location 　 Building Usage 　 　 Total area 　
Length
(m)		 　 Width
(m)		 　 Eave Height
(m)		 　
Roof material 　
Wall material 　
Design Load and Meteorological Conditions
Wind load
(kn/m2)		 　 Wind speed
(m/sec)		 　 Snow load
(kn/m2)		 　
Rainfall
Capacity		 　 Earthquake Grade 　
Please fill out the below information if your building has the mezzanine
Height of Mezzanine(m) 　 Usage of mezzanine 　
Live load on mezzanine(kn/m2) 　
Please fill out the below information if your building has the crane
Capacity
(t)		 　 Span
(m)		 　 Quantity 　
Hoisting height (m) 　 Other information about crane 　
