Nickel Plated Twist On Coax Connector 18mm For RG59 RG6(5C-FB) CATV Adaptor
Nickel Plated Twist On Coax Connector 18mm For RG59 RG6(5C-FB) CATV Adaptor
Nickel Plated Twist On Coax Connector 18mm For RG59 RG6(5C-FB) CATV Adaptor
Nickel Plated Twist On Coax Connector 18mm For RG59 RG6(5C-FB) CATV Adaptor
Nickel Plated Twist On Coax Connector 18mm For RG59 RG6(5C-FB) CATV Adaptor
Nickel Plated Twist On Coax Connector 18mm For RG59 RG6(5C-FB) CATV Adaptor
Specifications
Brand Name :
OEM Produce
Model Number :
Coaxial Connector
Certification :
CE. ROHS.
Place of Origin :
Hangzhou, China
MOQ :
30KM
Price :
0.2usd/pcs
Payment Terms :
TT. LC
Supply Ability :
5000km/ Month
Delivery Time :
20days after deposit
Packaging Details :
100M. 200M. 300M. 1000FT. 500M. Reel
Material :
Nickel Plated Alloy
Application :
RG59 RG6(5C-FB) CATV Adaptor
Size :
18mm
Waterproof Material :
Rubber
Type :
Twist On F Coaxial Connector
Description

Nickel Plated Twist On F Coaxial Connector 18mm for RG59 RG6(5C-FB) CATV Adaptor

F Male Twist-On Connector / Adapter

Description:

F Male Twist-On Connector

Twist-on connectors are placed on the stripped cable and finger tightened.

Material:

Body—zinc alloy, nickel plated

Net Weight: 3g/piece

Application:

The F connector is a coaxial RF connector commonly used for "over the air" terrestrial television, cable television and

universally for satellite television and cable modems, usually with RG-6/U cable or, in older installations, with RG-59/U cable.

The F connector is inexpensive, yet has good 75 Ω impedance match up to 1 GHz and has usable bandwidth up to several

GHz. Most male connectors have a matching threaded connecting ring, though push-on versions are also available.

Push-on F connector ends provide poor shielding against airborne signals (e.g., a nearby TV transmitter will interfere with

a CATV station).

Keywords: F Male Twist On Connector, F Male Twist On Adapter, F Connector for RG6, F Connector, CCTV Connector, cable

connector, coaxial connector, F-Connectors, F adapter, F adaptor, F plug RG6, connector,

Electronical Specifications:

Standard Cross Reference RCZ-6015
Voltage Rating AC 150V
With Standing Voltage AC 500V One Minute
Insulation Resistance 500M Ω Minute DC 500V
Contace Resistance 50 M Ω AT DC 1A
Impedance 75Ω
VSWR 1.2Max 0-1500MHz

F-TYPE Connectors are of low price and develop for NTSC TV Antenna etc.

Refined Zinc Alloy

Long Type: Length 20mm

Short Type: Length 17mm

(A)RG-58/U

(B)RG-59/U

(C)RG-6/U

Nickel Plated Twist On Coax Connector 18mm For RG59 RG6(5C-FB) CATV AdaptorNickel Plated Twist On Coax Connector 18mm For RG59 RG6(5C-FB) CATV AdaptorNickel Plated Twist On Coax Connector 18mm For RG59 RG6(5C-FB) CATV Adaptor
