RG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized Color
RG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized Color
RG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized Color
RG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized Color
RG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized Color
RG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized Color
RG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized Color
RG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized Color
RG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized Color
RG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized Color
Specifications
Place of Origin :
Hangzhou, China
Brand Name :
OEM Produce
Certification :
CPR. CE. ROHS.
Model Number :
RG59U
MOQ :
10km
Price :
FOB Shanghai Price: 12.00 USD/100m
Packaging Details :
100M. 200M. 300M. 1000FT. 500M. Reel
Delivery Time :
20days after deposit
Payment Terms :
TT. LC
Supply Ability :
5000km/ Month
Inner Conductor :
20AWG/0.81CU
Insulation :
3.7 Foam PE
Shield :
CCA 90%+ Golden Color Foil
Sheath :
PVC/ FR PVC/ LSZH
Color :
White or Customized
Packing :
305M/1000FT or Customized
Useful :
CCTV, CATV
Description

RG59 75 Ohm Coaxial Cable 0.81BC+CCA 90%+ Golden Color Foil CCTV CATV Wire

RG59 Coaxial cable

RG59 Coaxial Cables are generally used in video transmission, CCTV, Digital TV, Satellite TV system abd HFC broadband networks.

Advanced Features:

Presented below are key features of RG Series which are widely represented in different versions within this catalogue.

All of these products have some common features including:

--Closed cell Foamed PE Dielectric

--Attenuation Swept from 5MHz-2GHz

--High screening effectiveness, also know as Class A+/ Class A++ Screen Attenuation(AS) according to EN50117 SPECIFICATIONS

--Long-lasting stability of signal attenuation thanks to physical gas injected foam PE dielectric technology(skin-foam-skin)

--Coaxial cables with PVC Jacket, flexible thermo-plastic material commonly used on general purpose coaxial products. Temprature rating:-40℃ to 80℃

--Coaxial cables with PE outer sheath, strong enough to protect the coaxial core from the environment, must be used for outdoor / underground/ direct burial installations. Temprature rating:-55℃ to 85℃

--Characteristics of LSZH: flame and fire retartant, low smoke and fume emission, zero halogen and UV resistant

--Series of Anti-corrosion protection materials are available

--Cable marked Footage/ Meters

Details

Construction Material Diameter(mm)
Inner Conductor BC 0.81
Dielectric Foam PE 3.66
First Shield Bonded AL Foil 15
Second Shield CCA Braid 90%
Outer Jacket PVC WHITE 6.1

Electrical Characteristics

Impedance (Ω) 75±3
Capacitance (pF/m) 52±2
Velocity of Propagation(﹪) 85.0

Return Loss 5-1000MHz(dB)

≥22

Return Loss 1000-3000MHz(dB)

≥20

Attenuation(@20℃)

Frequency (MHZ) Min Attenuation (dB/100ft) Max Attenuation (dB/100m)
5 0.9 2.8
55 2.1 6.7
187 3.6 11.8
211 3.8 12.5
400 5.1 16.7
500 5.7 18.7
750 7.0 22.8
860 7.5 24.6
1000 8.0 26.3
1500 9.9 32.5
1800 10.9 35.6
2200 12.6 41.2
3000 13.8 45.2

RG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized Color

Loading Cables To Container and Delivery to Port

RG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized ColorRG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized ColorRG59U 75 Ohm Coaxial Cable 3.7Foam PE Golden Color Foil Customized Color

If you have technical support from an engineer, please let us know the type of cables you need, the inner conductor, the braiding coverage, the jakcet material and color, the packing length and design, and the application. We will help you choose the most suitable cable.

If you are not sure about certain specifications of the electric cables, please let us know your inquiry and we are very happy to give you professional technical advice and support services. Our company offer specific cables and wires consulting, design, OEM and manufacturing based on the customer's requirements and application scenarios to help customers create more business opportunities.
