FIBC Automatic Big Bag Fabric Cutting Machine

Description

It provides a simple solution for PP woven fabric roll cut to length and holing for producing big bag parts panel with basic cut: length cut and O/X holing.

A compact and automatic fabric cutting machine, it is designed as a whole structure instead of modularized design: all components in one structure, the set will be delivered with a ready to use condition, installation free.

If you need a multi-function automatic big bag fabric cutting machine to process U shape panel with O/X cut or gusseted tubular with I/U cut for one or two loop big bags, please click BigbagCUT for more information.

Function

1. The specially designed machine integrates the various main functions in jumbo bag cutting—punching like:Auto jumbo—fabric roll
feeding,Edge process control(EPC),Length—counting,Punching unit for “O” hole,Punching unit for “+” hole,Circle describing,
Linear—knife cutting,Jumbo—fabric feeding.
2. PLC control system.Color man—machine interface,which make date—setting,display,recording more clear and accurate,easier
operation.
3. Hydraulic automatic jumbo—fabric roll feeding&EPC unit,stable,simple and easy in operation.
4. Equipped import servo control system for precise and fast cutting.

Feature

All-in-one design ready to use delivery, installation free

Automatic operating machine

Air operated lift up changing of fabric roll

Length cut on ±5mm accuracy of 1mtr length fabric

Operating in English/Spanish/Russian languages on touching screen, one operator required

Speed variable, max. output appr. 28pcs/min

Motor driven deviation correction device edge control

Accuracy individual heating control smokeless panel heating alloy-steel hot cutter with fabric burn-proof and anti-carbonized cutting of a continuous heating in stable cutting temperature

Figure protection safety gate

Auto dot and marking

Specification
