PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
Specifications
Brand Name :
SHQI
Model Number :
985
Certification :
CE,ISO
Place of Origin :
SHANGHAI
MOQ :
1
Price :
USD**
Payment Terms :
L/C, T/T, Western Union, MoneyGram
Supply Ability :
100 units per month
Delivery Time :
28 days
Packaging Details :
container
Condition :
New
Dimension(l*w*h) :
Specific Model
Product name :
Factory produced stone aggregate crushing machine plant
After-sales service provided :
Engineers available to service machinery overseas
Color :
Customizable
Power(w) :
110kw
Name :
quarry stone crusher plant
Max feeding size :
300-500mm
Description

PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder

PFC Series Impact Crusher

PFC European impact crusher is manufactured according to advanced European technology, combined with working condition of sand and gravel industry. This kind of crusher can crush materials with max feed size less than 700mm and crushing strength less than 350 Mp. It is widely used for highway, water conservancy, electricity and construction.

PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder

please feel free contact us by whatsapp: 008615021099979
(wechat/Viber/line/IMO/facebook)

(100-150TPH) Hard Rock Mobile Crushing Mobile Jaw Crusher Portable Crushing Plant

This mobile crushing station consists of vibrating feeder and jaw crusher. It plays a role of primary crushing stage, which can crush the hard stone with size around 700mm into small aggregates size range from 80mm-140mm. Its capacity is around 110-320t/h.

(500TPH-600TPH) Medium Hard Rock

The stone production line (500tph-600tph) mainly consists of vibrating feeder, jaw crusher, 2 sets impact crushers, 2sets vibrating screens, etc. In order to meet the large-output requirement, this configuration is energy-saving and high-efficiency. It can crush medium hard rock into stone at the rate of 500TPH to 600TPH.

PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder

Specifications

No. Equipment Model Quantity Power(Kw)
1 Vibrating Feeder GZD1100X4200 1 15-18.5
2 Jaw Crusher PE750X1060 1 90-110
3 Chassis Tri-axial 1


(100-150TPH) Hard Rock Mobile Crushing Screening &Washing Plant Sand Making Plant

please feel free contact us by whatsapp: 008615021099979
(wechat/Viber/line/IMO/facebook)

Feature
1.Manufacturing technique is of world class
2.The movable jaw assembly is of more advanced technology. It adopts high quality welding technology, and the eccentric shaft is elaborate
3.Integral cast steel structure is adopted for bearing seat to ensure the complete match with the frame
4.Finite Element Analysis is adopted to strengthen the crusher
5.The crushing chamber adopts "V" shape structure, which makes the feeding port's actual width be in accordance with the nominal
6.Discharging port adjustment is quicker and more convenient. Wedge block adjustment device is easier, safer and faster
7.Larger and more wearable main bearing is used to lengthen the service life; The bearing capacity is higher and effective labyrinth seal also lengthens the lifespan
8.The teeth protection plate increases the length of jaw plate

  • PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
  • PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
  • PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
  • PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
  • PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
  • PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
  • PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
  • PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
    • PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
    • PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder
    • PFC Series Impact Crusher hydraulic industrial technology crushing technology manufactured sand vibrating feeder

    Specifications

    Model

    Specification

    (mm/inch)

    Feeding Opening

    ( mm)

    Ma×.Feeding Size

    (mm)

    Capacity

    (t/h)

    Power

    (kw)

    Weight

    (t)

    Dimension

    (mm)
    PFC1210 Φ1150×960(Φ46"×38") 1100×1030(44"×41") 400 90-160 90-110 18 2400×1870×2550
    PFC1214 Φ1150×1400(Φ46"×56") 1100×1430(44"×57") 500 130-200 132-160 22 2400×2310×2550
    PFC1315 Φ1300×1500(Φ52"×60") 1200×1530(48"×61") 600 180-320 160-200 29 2700×2570×2800
    PFC1318 Φ1300×1800(Φ46"×72") 1200×1830(48"×73") 700 240-400 200-250 34 2700×2870×2800
    PFC1415 Φ1400×1500(Φ56"×60") 1300×1530(52"×61") 700 300-480 200-250 38 2900×2700×3000
