Specifications
Brand Name :
SANROCK
Model Number :
985
Certification :
ISO9001,ISO,ENERGY SAVING,CE
Place of Origin :
CHINA
MOQ :
1
Price :
USD1
Payment Terms :
D/P, L/C, T/T, Western Union, MoneyGram
Supply Ability :
300 units per month
Delivery Time :
7-15 working days
Packaging Details :
container
Type :
High Pressure Crawler Drill,Drill Shank,Agricultural Hydroponics,Core Drilling Rig
After-sales service provided :
Engineers available to service machinery overseas,Video technical support
Warranty :
12 months
Usage :
Water Well
Power type :
Diesel
Condition :
New
Product name :
200m pneumatic tractor mounted water well drilling rig machine price
Drilling depth :
200m
Description
Product Features
● This model rig uses full hydraulic control, and the top drive to drive the rotation of drilling tools with very high drilling efficiency.

● Reasonable overall layout uses the tractor-mounted or full ground chassis for transportation with good maneuverability.

● Very flexible in difficult roads and can be widely used in many fields such as resource exploration of hydrology wells, coalbed methane, the shallow
layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation salvage work.

● The top-mounted driving head principal shaft has a great drift diameter, suitable for many kinds of construction work such as slurry drilling, air
drilling, and air foam drilling, meeting the demands for well-drilling at different terrain strata.
SPECIFICATION
FY200 CRAWLER WATER WELL DRILLING RIG
Drilling Depth 200m
Drilling Diameter 140-305mm
One-Time Advance Length 3.40m
Walking Speed 2.50km/h
Climbing Angles 30 degree
Engine Power 68KW
Work Air Pressure 1.7-3.0 Mpa
Air Consumption 17-30m3/min
Drill Pipe Length 2m, 3m
Drill Pipe Diameter 76mm, 89mm
Rig Lifting Force 12 ton
Rotary Speed 40-70 rpm
Rotary Torque 3500-4800 N.m
Weight 5800KG
Dimensions 4000*1750*2450mm

==========================================================================

FY180/FY200 180m 200m STEEL TRACK CRAWLER WATER WELL DRILLING machine portable water well drilling rigs deep

Product Features

● This model rig uses full hydraulic control, and the Top drive to drive the rotation of drilling tools with very high drilling efficiency.

● Reasonable overall layout uses the tractor-mounted or full ground chassis for transportation with good maneuverability.

● Very flexible in difficult roads and can be widely used in many fields such as resource exploration of hydrology wells, coalbed methane, the shallow

layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation salvage work.

● The top-mounted driving head principal shaft has a great drift diameter, suitable for many kinds of construction work such as slurry drilling, air
drilling, and air foam drilling, meeting the demands for well-drilling at different terrain strata.
SPECIFICATIONS
FY180 CRAWLER WATER WELL DRILLING RIG
Drilling Depth 180m
Drilling Diameter 140-254mm
One-Time Advance Length 3.30m
Walking Speed 2.50km/h
Climbing Angles 30 degree
Engine Power 55KW
Work Air Pressure 1.7-2.5 Mpa
Air Consumption 17-30m3/min
Drill Pipe Length 2m, 3m
Drill Pipe Diameter 76mm, 89mm
Rig Lifting Force 10 ton
Rotary Speed 45-65 rpm
Rotary Torque 3200-4600 N.m
Weight 4500KG
Dimensions 3800*1500*2200mm
FY200 RUBBER TRACK CRAWLER WATER WELL DRILLING RIG
Drilling Depth 200m
Drilling Diameter 140-305mm
One-Time Advance Length 3.40m
Walking Speed 2.50km/h
Climbing Angles 30 degree
Engine Power 68KW
Work Air Pressure 1.7-3.0 Mpa
Air Consumption 17-30 m3/min
Drill Pipe Length 2m, 3m
Drill Pipe Diameter 76mm, 89mm
Rig Lifting Force 12 ton
Rotary Speed 40-70 rpm
Rotary Torque 3500-4800 N.m
Weight 5000KG
Dimensions 3900*1650*2250mm
==============================================
please feel free contact us, whatsapp/wechat::008615021099979
====================================================
FY600/F800 CRAWLER WATER WELL DRILLING RIG
FY600/F800 Crawler Water Well Drilling Rig
DESCRIPTION

600M 800M depth Water Well Drilling Rig
FY200 200m CRAWLER HYDRACULIC WATER WELL DRILLING RIG machine portable water well drilling rigs deep drill rig truckFY200 200m CRAWLER HYDRACULIC WATER WELL DRILLING RIG machine portable water well drilling rigs deep drill rig truck
Product Features

● This model rig uses full hydraulic control, and the Top drive to drive the rotation of drilling tools with very high drilling efficiency.


● Reasonable overall layout uses the tractor-mounted or full ground chassis for transportation with good maneuverability.

● Very flexible in difficult roads and can be widely used in many fields such as resource exploration of hydrology wells, coalbed methane, the shallow
layer of shale gas, terrestrial heat, etc, and can also be used for coal-mine gas exploitation salvage work.
● The top-mounted driving head principal shaft has a great drift diameter, suitable for many kinds of construction work such as slurry drilling, air
drilling, and air foam drilling, meeting the demands for well-drilling at different terrain strata.

SPECIFICATION
FY600 CRAWLER WATER WELL DRILLING RIG
Drilling Depth 600m
Drilling Diameter 140-350mm
One-Time Advance Length 6.60m
Walking Speed 2.50km/h
Climbing Angles 30 degree
Engine Power 118KW
Work Air Pressure 1.7-3.5 Mpa
Air Consumption 17-42m3/min
Drill Pipe Length 2m, 3m, 6m
Drill Pipe Diameter 102mm, 108mm, 114mm
Rig Lifting Force 28 ton
Rotary Speed 45-115 rpm
Rotary Torque 8500-11000 N.m
Weight 12000KG
Dimensions 6000*2200*2850mm

FY800 CRAWLER WATER WELL DRILLING RIG
Drilling Depth 700m
Drilling Diameter 140-400mm
One-Time Advance Length 6.60m
Walking Speed 2.50km/h
Climbing Angles 30 degree
Engine Power 140KW
Work Air Pressure 1.7-3.5 Mpa
Air Consumption 17-42m3/min
Drill Pipe Length 2m, 3m, 6m
Drill Pipe Diameter 102mm, 108mm, 114mm
Rig Lifting Force 30 ton
Rotary Speed 55-120 rpm
Rotary Torque 8850-13150 N.m
Weight 13000KG
Dimensions 6100*2200*2900mm



==================================================================================
please feel free contact us, whatsapp/wechat::008615021099979

=====================================================

FY600 CRAWLER WATER WELL DRILLING RIG
Drilling Depth 600m
Drilling Diameter 140-350mm
One-Time Advance Length 6.60m
Walking Speed 2.50km/h
Climbing Angles 30 degree
Engine Power 118KW
Work Air Pressure 1.7-3.5 Mpa
Air Consumption 17-42m3/min
Drill Pipe Length 2m, 3m, 6m
Drill Pipe Diameter 102mm, 108mm, 114mm
Rig Lifting Force 28 ton
Rotary Speed 45-115 rpm
Rotary Torque 8500-11000 N.m
Weight 12000KG
Dimensions 6000*2200*2850mm

FY800 CRAWLER WATER WELL DRILLING RIG
Drilling Depth 700m
Drilling Diameter 140-400mm
One-Time Advance Length 6.60m
Walking Speed 2.50km/h
Climbing Angles 30 degree
Engine Power 140KW
Work Air Pressure 1.7-3.5 Mpa
Air Consumption 17-42m3/min
Drill Pipe Length 2m, 3m, 6m
Drill Pipe Diameter 102mm, 108mm, 114mm
Rig Lifting Force 30 ton
Rotary Speed 55-120 rpm
Rotary Torque 8850-13150 N.m
Weight 13000KG
Dimensions 6100*2200*2900mm
