Programmable DC Energy Saving And Environmental Protection Electronic Load
Programmable DC Energy Saving And Environmental Protection Electronic Load
Programmable DC Energy Saving And Environmental Protection Electronic Load
Programmable DC Energy Saving And Environmental Protection Electronic Load
Specifications
Brand Name :
CPET
Model Number :
8509
Place of Origin :
China
MOQ :
5sets
Price :
800dollars/set
Payment Terms :
D/A, T/T
Supply Ability :
500sets/month
Delivery Time :
10 work days
Packaging Details :
Wooden case packing
Channel number :
8CH
Single channel power :
250W
Pull mode :
CC/CV/CR/CP
Description

Programmable DC Energy Saving And Environmental Protection Electronic Load

Scope of application

Programmable DC Energy Saving And Environmental Protection Electronic Load

Apply to the burn-in testing of Adapter, Industrial power supply, Switching power supply,LED driver and other kind of power supply
Apply to aging vehicles ,burn-in cabinet,burn-in room,automatic burn-in testing system
Battery discharge burn-in testing

Outstanding functions

Programmable DC Energy Saving And Environmental Protection Electronic Load

1. Channel take independent control
2. Efficiency is more than 85%
3. Support Von setting
4. CC/CV/CR/CP load mode
5. Output take EMC progress
6. Harmonic correction of power harmonic
7. Support parallel connection of channel under CC load mode
8. RS485 Communication Structure is industrial grade

Performance parameters

Programmable DC Energy Saving And Environmental Protection Electronic Load

Model CP8508 CP8509 CP8512 CP8513
Input voltage range 3~60Vdc 10~100Vdc 3~60Vdc 3~60Vdc
Input current range 0.5~20Adc 0.5~10Adc 0.5~40Adc 0.5~60Adc
Channel number 8CH 8CH 4CH 6CH
Single channel power 250W 250W 550W 1100W
Pull mode CC/CV/CR/CP CC/CV/CR/CP CC,CV,LED,CR,CP CC,CV,LED,CR,CP
Votage comtrol precision ±2%+0.5%FS ±1%+0.2%FS ±2%+0.5%FS ±2%+0.5%FS
Voltage accuoacy ±1%+0.5%FS ±1%+0.2%FS ±1%+0.5%FS ±1%+0.5%FS
Current control
accuracy		 ±2%+0.5%FS ±1%+0.2%FS ±5%+0.5%FS ±3%+0.5%FS
urrent readback
accuracy		 ±1%+0.5%FS ±1%+0.2%FS ±1%+0.5%FS ±1%+0.5%FS
Output voltage/
current		 72V/28A 120V/17A 56V/57A RS-485
Communication mode RS-485 RS-485 RS-485 RS-485
Paired inverter CP5309 CP5310 CP5309 CP5309
