5mm 6mm Belleville Spring Washers Spring Steel Strip With Elastic Disc
5mm 6mm Belleville Spring Washers Spring Steel Strip With Elastic Disc
5mm 6mm Belleville Spring Washers Spring Steel Strip With Elastic Disc
5mm 6mm Belleville Spring Washers Spring Steel Strip With Elastic Disc
Specifications
Brand Name :
Kiande
Model Number :
KD-05/15
Certification :
ISO9001
Place of Origin :
CHINA
MOQ :
1000 piece
Price :
Custmized
Payment Terms :
L/C, T/T
Supply Ability :
100000/days
Packaging Details :
carton box or plywood cca
Description :
Belleville Spring Washers
Surface :
Dacro
Model :
φ75*5mm
Material :
spring steel strip
Usage :
Increase the load capacity
Thickness :
5mm,6mm
Description

Belleville Spring Washers with elastic dics made by spring steel strip

Belleville washer is to absorb loads by acting as a spring. When a load is applied a

Belleville washer, the washer compresses. At the same time, the Belleville washer

exerts an equal amount of force against the object.

5mm 6mm Belleville Spring Washers Spring Steel Strip With Elastic Disc

5mm 6mm Belleville Spring Washers Spring Steel Strip With Elastic Disc

Model Material Hole Diameter Surface Treatment
φ37*3mm 65Mn φ8.5mm Galvanized Treatment
φ74*4mm 65Mn φ13mm Dacromet Treatment
φ75*5mm 65Mn φ13mm Dacromet Treatment
φ76*5mm 65Mn φ13mm Dacromet Treatment
φ90*6mm 65Mn φ13mm Dacromet Treatment

Joint block is operatable by one / two bolts.
Joint assembly can be removed / installed at any time in installed condition.
Disc spring washer are used in Uniblock joint to uniformly distribute pressure.
Recommended torque for tightening is 7 Kg-mtr.
These joints are specially designed to accommodate thermal expansion of busbars and housing.
