M12x115 Compact Joint Torque Control Bolts Busbar Accessories With Galvanized
M12x115 Compact Joint Torque Control Bolts Busbar Accessories With Galvanized
M12x115 Compact Joint Torque Control Bolts Busbar Accessories With Galvanized
M12x115 Compact Joint Torque Control Bolts Busbar Accessories With Galvanized
M12x115 Compact Joint Torque Control Bolts Busbar Accessories With Galvanized
M12x115 Compact Joint Torque Control Bolts Busbar Accessories With Galvanized
Specifications
Brand Name :
Kiande
Model Number :
K.A.L.J.M12
Certification :
ISO9001
Place of Origin :
China
MOQ :
10000 piece
Price :
customized
Payment Terms :
L/C, T/T
Supply Ability :
100000 pieces per month
Delivery Time :
5-8 working days
Packaging Details :
carton
Name :
M10 Joint Torque Bolt
Packing :
Plywood
Usage :
used for busbar joint
Material :
High tensile steel
Other name :
High Tensile Double Head Bolt
Other name 2 :
Shear off Nut
Other name 3 :
Busway Joint Double Head Bolt
Description

M12*115 Compact Busbar Joint Torque Bolt for Busbar Joint

Features


Installed in joint for insulation
Material: 8.8 grade high tensile steel
Size and color can be customized

M12x115 Compact Joint Torque Control Bolts Busbar Accessories With Galvanized

Model Class Size of Square Nut Thread Length Torque Force Color
M12*115 8.8 30*30mm/27*27mm 45~65mm 70 ~90 N.M Yellow/White Galvanized
M12*120 8.8 30*30mm/27*27mm 45~65mm 70 ~90 N.M Yellow/White Galvanized
M12*125 8.8 30*30mm/27*27mm 45~65mm 70 ~90 N.M Yellow/White Galvanized
M12*130 8.8 30*30mm/27*27mm 45~65mm 70 ~90 N.M Yellow/White Galvanized
M12*140 8.8 30*30mm/27*27mm 45~65mm 70 ~90 N.M Yellow/White Galvanized
M12*165 8.8 30*30mm/27*27mm 45~65mm 70 ~90 N.M

Yellow/White Galvanized

What is Busbar trunking system?

A busbar trunking system is the most advanced solution for distributing medium-large power within a building in order to supply the power for the operationof light fittings situated in warehouses, exhibition halls and wherever speed of installation is required. The busbar is also frequently used for feeding the main incomer (horizontal and vertical) of buildings used for commercial activities, thus making it possible to meet installation schedules and providing a final solution with remarkable technical advantages compared to an equivalent system installed with cables and cabletrays.

Advantages of busbar trunking systems:

  1. Straightforward network configuration;
  2. Low space requirements;
  3. Easy retrofitting in case of changes of locations and consumer loads;
  4. High short-circuit strength and low fire load;
  5. Increased planning security.
