ZEMO Elbow Fitting Welding Machine , 380V 50/60hz HDPE Pipe Welder
ZEMO Elbow Fitting Welding Machine , 380V 50/60hz HDPE Pipe Welder
ZEMO Elbow Fitting Welding Machine , 380V 50/60hz HDPE Pipe Welder
ZEMO Elbow Fitting Welding Machine , 380V 50/60hz HDPE Pipe Welder
Specifications
Brand Name :
ZEMO
Model Number :
SHG-MA315/90H
Certification :
CE, ISO
Place of Origin :
China
MOQ :
1 SET
Price :
negotiation
Payment Terms :
D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability :
100 SETS/Week
Delivery Time :
7-15 working days after payment
Product Name :
315MM HDPE Elbow Fitting Welding Machine
Size :
90-315MM
Voltage :
380V,50/60HZ
Application :
Fabricating Elbow ,Tee . Cross and Y type
Warranty :
2 Years
Automatic grade :
Automatic
Control Mode :
Constant voltage .
Power :
7.25KW
WhatsApp :
+86-13933031824
Tem.Deviation in Surface (170-250: :
≤±7 ℃
Description

HDPE Elbow Fitting Welding Machine Description

SHG -MA315/90 HDPE Elbow Fitting Welding Machine is designed to fabricate fittings by joining pipe segments, with the help of
special jaws. This machine is mainly used for welding elbows, tees, crosses and wyes from Ø90 to 315mm with materials of HDPE PP..

Also used to lengthen the injection moulded fitting and make an integrated fitting

HDPE Elbow Fitting Welding Machine ​Specification

Product Name HDPE Elbow Fitting Welding Machine
Model
SHG-MA315/90H
Pipe size (mm)
,90,110,125,140,160 180,200.225,250.280,315
Heating plate Max. Temperature
270℃
Temp.deviation in surface (170-250 ℃)
(170~250 ℃ ) ±5 ℃
Pressures Adjustable Ranges
0 ~ 16MPa
Working Voltage
380V,50/60Hz
Heating plate power
5KW
Planing tool power
0.75KW
Hydraulic unit power
1.5KW
Total Power
7.25KW
Weight
706KG (Don't include optional parts )
Packing
Cases
8 plywood cases
Volume
3.1CBM


ZEMO Elbow Fitting Welding Machine , 380V 50/60hz HDPE Pipe Welder
ZEMO Elbow Fitting Welding Machine , 380V 50/60hz HDPE Pipe WelderZEMO Elbow Fitting Welding Machine , 380V 50/60hz HDPE Pipe Welder

HDPE Elbow Fitting Welding Machine ​​Features

1. HDPE Elbow Fittings Welding Machine SHG-MA315/90 with printing is suitable for fabricating elbow, tee, cross and we shape (45 and 609) Fittings of PE, PP, PVDF in work shop
2. Base on the integrated design, if welded different fitting you just need to replace the corresponding fixture
3. Heating plate uses independent temperature control system, removable PTFE coated
4. Electric face with safety limit switch can avoid the milling cutter accidental starting.
5. Low starting pressure ensures reliable welding quality of small pipes.
6.Separate two-channel timer can show both of soaking and cooling time
7. High-precision and shockproof pressure meter displays records clearly
8. Heating plate, milling cutter and support plate is on the linear guide track
9. Complies with 98/37 and 73/23 EEC standards
10. Optional components: short flange welding fixture, short pipe welding fixture.
Package
ZEMO Elbow Fitting Welding Machine , 380V 50/60hz HDPE Pipe WelderZEMO Elbow Fitting Welding Machine , 380V 50/60hz HDPE Pipe Welder

After-sales Service:

All Machine Quality Guarantee: 24 months.--If any parts broken or does not work under normal operating,
we provide them for free
