1/4- 7/8 Copper Nickel Tube , Cu - Ni 90/10 C70600 Seamless Copper Nickel Tubing
1/4- 7/8 Copper Nickel Tube , Cu - Ni 90/10 C70600 Seamless Copper Nickel Tubing
1/4- 7/8 Copper Nickel Tube , Cu - Ni 90/10 C70600 Seamless Copper Nickel Tubing
1/4- 7/8 Copper Nickel Tube , Cu - Ni 90/10 C70600 Seamless Copper Nickel Tubing
1/4- 7/8 Copper Nickel Tube , Cu - Ni 90/10 C70600 Seamless Copper Nickel Tubing
1/4- 7/8 Copper Nickel Tube , Cu - Ni 90/10 C70600 Seamless Copper Nickel Tubing
1/4- 7/8 Copper Nickel Tube , Cu - Ni 90/10 C70600 Seamless Copper Nickel Tubing
1/4- 7/8 Copper Nickel Tube , Cu - Ni 90/10 C70600 Seamless Copper Nickel Tubing
Specifications
Brand Name :
TOBO/TPCO/TISCO/VALIN/METAL
Model Number :
Copper Nickel Tube
Certification :
ISO/PED/TUV/SGS/LR/BV
Place of Origin :
China/Japan/Germany
MOQ :
1pc
Price :
USD Depend on
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
500 tons per mouth
Delivery Time :
10-90 days
Packaging Details :
Export standard package: bundled wooden box or be required
Standard :
ASME SB165, SB111, etc.
OD :
6-219.1mm
WT :
0.7-12.7mm
Length :
0-38000mm
Material :
Copper (C10200,C11000,C10100,C10200,C12000,)C11600,
Description

Copper Nickel Tube cu-ni 90/10 C70600 seamless copper nickel alloy tube, copper tube

Small diameter copper tube

1. Shape : Copper Pipe Pancake Coil and Copper Straight Pipe

2. Outside Diameter: 1/4"- 7/8"and 1/4" -4 1/8"

3. Length: 5.8m, 6m, 15m, 30m.

4. Temper: Hard, Half Hard, Soft

5. Standard: ASTM B280, EN12735, JIS H3300, AS1571.

6. Package: Carton Box, wooden pallet .

7.MOQ:300kgs each size

8.Payment:TT or LC

9.Delivery:within 15 days after receipt the deposit.

Specifications (for reference only)

OD: 4.0mm, Thickness: 0.40/0.45/0.50mm

OD: 4.76mm=3/16'', Thickness: 0.35mm - 1.00mm

OD: 6.00mm, Thickness: 0.35mm - 1.00mm

OD: 6.35mm=1/4'', Thickness: 0.35mm - 1.20mm

OD: 7.94mm=5/16'', Thickness: 0.30mm - 1.20mm

OD: 8.00mm, Thickness: 0.30mm - 1.20mm

OD: 9.52mm=3/8'', Thickness: 0.30mm - 1.50mm

OD: 12.00mm, Thickness: 0.35mm - 1.50mm

OD: 12.70mm=1/2'', Thickness: 0.35mm - 1.50mm

OD: 14.00mm, Thickness: 0.40mm - 1.50mm

OD: 15.00mm, Thickness: 0.40mm - 1.50mm

OD: 15.88mm=5/8'', Thickness: 0.40mm-1.50mm

OD: 16.00mm, Thickness: 0.50mm - 1.50mm

OD: 19.05mm=3/4'', Thickness: 0.60mm - 1.50mm

OD: 28.57mm = 1 1/8'', Thickness: 0.70mm - 1.50mm

Description Copper Nickel tube
Standards ASTM, AISI, JIS, SUS, EN, DIN, BS, GB
Material

ASTM :Copper (C10200,C11000,C10100,C10200,C12000,)C11600,

,

C46200.C46400,C26130,C65600,)

Bronze(C50500,C51100,C52100,C60800,C61000,C61900,C63010,

C62300,C63000,C63280,C63020,C17200,C17000,

C17500,C17510,C18200,C18100,C18200,C16200,C19400,C14500)

Cupronickel(C70400,C71000,C71300,C71500,C70400,C70600,

C75200,C77000,C75400,C79000,C79200)
Specifications

thickness 1mm to 220mm ,diameter 6mm to 2500mm

or as customer required
Price Term EX-Work, FOB, CFR, CIF
Payment Term T/T, L/C, Western Union
Delivery Time According to customer' s quantity.
Main Market

USA ,Germany ,India ,Iran,Dubai,Iraq,Viet Nam,Ireland,Sinagpore,

and so on .
Package Export standard package: bundled wooden box or be required;
Application

1.Straight Copper Tubes for ACR and Refrigeration

2.Inner-grooved copper tube for ACR and Refrigeration

3.Copper Pipe for Transportation System of water, gas and oil

2.Chemical composition:

Copper Nickel Tube
Grade Cu Pb Fe Zn Mn Ni+Co
C70400 Balance ≤0.05 1.3-1.7 ≤1.0 0.3-0.8 4.8-6.2
C70600 Balance ≤0.05 1.0-1.8 ≤1.0 ≤1.0 9.0-11.0
C70620 ≥86.5 ≤0.02 1.0-1.8 ≤0.50 ≤1.0 9.0-11.0
C71000 Balance ≤0.05 0.5-1.0 ≤1.0 ≤1.0 19.0-23.0
C71500 Balance ≤0.05 0.4-1.0 ≤1.0 ≤1.0 29.0-33.0
C71520 ≥65.0 ≤0.02 0.4-1.0 ≤0.50 ≤1.0 29.0-33.0
