304 316 Stainless Steel Welded Tube for Furniture ASTM A249 / 269 , 0.6mm-3mm Wall
304 316 Stainless Steel Welded Tube for Furniture ASTM A249 / 269 , 0.6mm-3mm Wall
304 316 Stainless Steel Welded Tube for Furniture ASTM A249 / 269 , 0.6mm-3mm Wall
304 316 Stainless Steel Welded Tube for Furniture ASTM A249 / 269 , 0.6mm-3mm Wall
304 316 Stainless Steel Welded Tube for Furniture ASTM A249 / 269 , 0.6mm-3mm Wall
304 316 Stainless Steel Welded Tube for Furniture ASTM A249 / 269 , 0.6mm-3mm Wall
304 316 Stainless Steel Welded Tube for Furniture ASTM A249 / 269 , 0.6mm-3mm Wall
304 316 Stainless Steel Welded Tube for Furniture ASTM A249 / 269 , 0.6mm-3mm Wall
304 316 Stainless Steel Welded Tube for Furniture ASTM A249 / 269 , 0.6mm-3mm Wall
304 316 Stainless Steel Welded Tube for Furniture ASTM A249 / 269 , 0.6mm-3mm Wall
Specifications
Brand Name :
TOBO/TPCO/TISCO/VALIN/METAL
Model Number :
ASTM A554, A312, A249, A269 And A270,A688
Certification :
ISO/PED/TUV/SGS/LR/BV
Place of Origin :
China/Japan/Germany
MOQ :
100KGS
Price :
negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
1500 tons per month
Delivery Time :
15days->
Packaging Details :
in plastic bags then in bundles
Standard :
ASTM A554, A312, A249, A269 And A270,A688
color :
White, silver
Size :
1/2"-48"
type :
Stainless Steel Welded Tube
Description

304 316 201 202 Stainless Steel Welded Tube for Furniture ASTM A554 A312 A249

Detailed Product Description

Test: Squash Test, Extended Test, Water Pressure Test, Crystal Rot Test, Heat Treatment, NDT Application: Handrail,weldmesh Screen,door,window, Balcony,fence,furniture,etc
Material Grade: 304,316,201,202, 316L,430 Outer Diameter: 6mm-101.6mm
Standard: ASTM A554, A312, A249, A269 And A270,A688 Surface: Polished
Type: Stainless Steel Welded Tube / Pipe Wall Thickness: 0.6mm-3mm

304 316 201 202 Stainless Steel Welded Tube for Furniture ASTM A554 A312 A249


Quick Detail:

Welded Stainless Steel tube As per ASTM A249/A269,polished, for fluid and decorative
1 Standard: ASTM A249/269
2 Material:304,316,201,202, 316L,430
3 OD: 6mm-101.6mm
Wall: 0.6mm-3mm
4 Surface:polished

Name Stainless steel welded tube
Standard ASTM A554, A312, A249, A269 and A270,A688
Material Grade 304,316,201,202, 316L,430
Size Range 20x10mm--100x50mm,10x10mm-100x100mm, 9.53-101.6mm, we can also accept sizes above 101.6mm
Thickness 0.3mm - 3.0mm
Length 6m or as customers' request

Tolerance		 a) Outer Diameter: +/- 0.2mm
b) Thickness: +/- 0.02mm
c) Length: +/- 5mm
Surface 180G, 320G Satin / Hairline(Matt Finish, Brush, Dull Finish)
400G, 600G Mirror finish
Application Handrail,weldmesh screen,door,window, balcony,fence,furniture,etc
Test Squash test, Extended test, Water pressure test, Crystal rot test, Heat treatment, NDT




Chemical Composition of Material
Composition

Material		 201 202 304 316L 430
C ≤0.15 ≤0.15 ≤0.08 ≤0.35 ≤0.12
Si ≤1.00 ≤1.00 ≤1.00 ≤1.00 ≤1.00
Mn 5.5-7.5 7.5-10 ≤2.00 ≤2.00 ≤1.00
P ≤0.06 ≤0.06 ≤0.045 ≤0.045 ≤0.040
S ≤0.03 ≤0.03 ≤0.030 ≤0.030 ≤0.030
Cr 13-15 14-17 18-20 16-18 16-18
Ni 0.7-1.1 3.5-4.5 8-10.5 10-14
Mo 2.0-3.0

Mechanical Property		 Material Item 201 202 304 316
Tensile Strength ≥535 ≥520 ≥520 ≥520
Yield Strength ≥245 ≥205 ≥205 ≥205
Extension ≥30% ≥30% ≥35% ≥35%
Hardness (HV) <105 <100 <90 <90



The welded stainless steel pipe is made from stainless steel by electric welding or sheet metal strips by means of forming and welding. Electrically welded tube is made of thermally without subsequent processing and hot-reducing.


Our Advantages:

1, Direct material sourcing from Bao Steel, ZPSS, TISCO.
2, More than 5 processing mills to produce the welded titanium tube for us. And also we own a steel tube mill.
3, Strong business cooperation with Bao Steel and Shanghai Minmetals.
4, More than usd$50,000,000 annual turnover.

304 316 Stainless Steel Welded Tube for Furniture ASTM A249 / 269 , 0.6mm-3mm Wall304 316 Stainless Steel Welded Tube for Furniture ASTM A249 / 269 , 0.6mm-3mm Wall
