0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600
0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600
0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600
0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600
0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600
0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600
0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600
0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600
0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600
0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600
Specifications
Brand Name :
TOBO
Model Number :
TOBO-94
Certification :
SGS
Place of Origin :
China
MOQ :
1PCS
Price :
1 USD PER PCS
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
500 TON PER MONTH
Delivery Time :
7-15 WORK DAYS
Packaging Details :
by Plywood case, about 1 metric ton per case.
product name :
TOBO Copper Nickel Tube
material :
C70600
type :
Seamless
Thickness: :
0.1mm-300mm
standard :
ASTM B359
place of origin :
Shanghai China
Outer Diameter :
3.5mm-500mm
Description

High Quality Copper Nickel CuNi Condenser Tube / Pipe C706 90/10

Product Detail

DESIGNATION: COPPER NICKEL, 90-10%.
This alloy is highly resistant to corrosion by turbulently flowing sea water. Tests and many years of service in tide water stations indicates to be an excellent condenser tube alloy for salt water use.
Copper nickel tubes 90-10% 706 are normaly produced in annealed temper.

Feasible Dimensions

Copper Nickel tube C70600 ASTM B111

The seamless copper nickel pipe/tube C70600 which is widely used for Evaporator,Heat Exchanger,Condenser,Distiller.

under standard ASTM B111, we can provide alloy tube C71500, C70600, C71640, etc.

Copper Nickel tubes, 10% – C70600 - exhibits excellent resistance to impingement attack. It is also highly resistant to SCC. This alloy is suitable for Marine condenser tube installations in place of Aluminum Brass, especially where higher water velocities are encountered.

UNS No. C70600 – BSI No. CN102 – ISO Name CuNi10Fe1Mn
Chemical Comp. (%) Cu rem / Ni 9 ~ 11 / Pb 0.05 / Fe 1 ~ 1.8 / Zn 1 max / Mg 1 max
ASTM Spec. B 111, B 395, B 466, B 552
ASME Spec. SB 111, SB 395, SB 466
Applications Condenser, Evaporator and Heat Exchanger tubes; Distiller tubing; Salt Water piping.
Temper O61 Annealed / H55 Light-Drawn

Properties *
Density 0.323 lb/in³
Tensile Strength min.- O61 -/- H55 40 ksi -/- 45 ksi
Yield Strength min.- O61 -/- H55 15 ksi -/- 35 ksi
CTE, linear 9.5 10-6/°F @ 70.0 – 570 °F
Specific Heat Capacity 0.09 BTU/lb-°F @ 70ºF
Thermal Conductivity 26 BTU/ft2/ft/h/°F @ 70.0 °F
Melting Point 2010 – 2100 °F

0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600

Send your message to this supplier

0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600

0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600

0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600

Quality Policy

Fully satisfy our customers, making products of copper and its alloys, using processes that are continuously improved in order to:
- Meet customer requirements.

- Control and prevent any environmental impact.

- Control and prevent risks in the process.

- Comply with legal and other applicable requirements.

Certifications

0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600

Equipments

0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600

Packaging & Shipping


0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600

0.1mm - 300mm Thickness Copper Nickel CuNi Condenser Pipe C715 70 / 30% ASTM B111 C70600

FAQ

1.Can we supply the sample ?

Yes,we can supply the sample of copper nickel pipe.You can tell us the detail size.

2.Can we accept customize?

Yes,we can.We can manufacture as customer's requirement.You can send the CAD or drawing to us.

3.Quality problem?

According to the standard for production.And the products must pass the quality inspection department.We also accept Third Part Inspection.

4.Delivery time?

Prompt delivery for standard size,or under the contract.

5.Payment term?

Under the contract.

6.Other problem?

You can contact our customer service staff to ask help.
