API MSS JIS DIN 90 Degree Carbon Steel Pipe Elbows Black 1.5D - 10D R
API MSS JIS DIN 90 Degree Carbon Steel Pipe Elbows Black 1.5D - 10D R
API MSS JIS DIN 90 Degree Carbon Steel Pipe Elbows Black 1.5D - 10D R
API MSS JIS DIN 90 Degree Carbon Steel Pipe Elbows Black 1.5D - 10D R
API MSS JIS DIN 90 Degree Carbon Steel Pipe Elbows Black 1.5D - 10D R
API MSS JIS DIN 90 Degree Carbon Steel Pipe Elbows Black 1.5D - 10D R
API MSS JIS DIN 90 Degree Carbon Steel Pipe Elbows Black 1.5D - 10D R
API MSS JIS DIN 90 Degree Carbon Steel Pipe Elbows Black 1.5D - 10D R
Specifications
Brand Name :
TOBO
Model Number :
ANSI B 16.9/ANSI B16.49/API/MSS/JIS/DIN
Certification :
SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Place of Origin :
China
MOQ :
100KGS
Price :
negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
1500 tons per month
Delivery Time :
15days->
Packaging Details :
in plastic bags then in bundles
Standard :
ANSI B 16.9/ANSI B16.49/API/MSS/JIS/DIN
color :
Black
Material :
Carbon Steel
type :
ELBOW
Description

API MSS JIS DIN 90 Degree Carbon Steel Pipe Elbows Black 1.5D - 10D R

Quick Detail:

Name: A403 WP316 Stainless elbow
Size: 1/2”-48”
Thickness: SCH10-SCH160 XXS
Material: Stainless steel, alloy steel
Angle: 45°, 90°, 180°

Description:
A403 WP316 Stainless Steel Elbows SCH10 - SCH160 XXS , 45°, 90°, 180°
Elbow, Material including stainless, Carbon steel,
Alloy steel.
Specifications:

Weld

Seamless

Nominal size

DN250-DN1800

DN15-DN700

Wall thickness

STD, XS,XXS,SCH10,SCH20,SCH30,SCH40,SCH60,SCH80,SCH160, etc.

Bending radius

R=1.5D-10D

Bending Angle

45°, 90°, 180°

Stanard

ASME

ANSI B16.9, ANSI B16.28, MSS SP75

DIN

DIN2605, DIN2615, DIN2616, DIN2617, DIN28011

SGP

JIS B2313

EN

EN10253-1, EN10253-2

Material



ASTM

Carbon steel: A234 WPB

Stainless steel: A403 WP304, A403 WP304L, A403 WP316, A403 WP316L, A403 WP321

Alloy steel: A234 WP12, A234 WP11, A234 WP22, A234 WP5, A420 WPL6, A420 WPL3

DIN

Carbon steel: St37.0, St35.8, St45.8

Stainless steel: 1.4301, 1.4306, 1.4401, 1.4571

Alloy steel: 1.7335, 1.7380, 1.0488 (1.0566)

JIS

Carbon steel: PG370, PT410

Stainless steel: SUS304, SUS304L, SUS316, SUS316L,SUS321

Alloy steel: PA2, PA23, PA24, PA25, PL380

GB

10#,20#,20G,20R,Q235, 16Mn, 16MnR, 1Cr5Mo,12CrMo,15CrMo, 15CrMoG, 12Cr1MoVG, 12Cr1MoV.

TOBOGROUP deal with stainless steel welded pipe and tube already more than 10 years,

every year sell
more than 80000 tons of stainless steel pipe and tube. Our client already cover more than 45 countries.
Our stainless steel seamless pipe and tube was width used in Mining, Energy,

Petrochemical, Chemical
Industry, Food plant, Paper plant, Gas and Fluid Industry etc.

Why choose us!
1. We are the specialized supplier of stainless steel materials, can provide the best price!
2. We have more than 30 years experience in exporting products to worldwide countries, can provide the high quality products!
3. We have three thousand tons of stock in warehouses with abundant capital. Furthermore, we offer charge sales, credit and 7-day 24-hour services.
4. Wide excellent experiences with after-sale service.
5. Every process will be checked by responsible QC which insures every product's quality.
6. Professional packing teams which keep every packing safely.
7. Trial order can be done in very short time.
8. Samples can be provided as your requirements.

API MSS JIS DIN 90 Degree Carbon Steel Pipe Elbows Black 1.5D - 10D R
API MSS JIS DIN 90 Degree Carbon Steel Pipe Elbows Black 1.5D - 10D R
API MSS JIS DIN 90 Degree Carbon Steel Pipe Elbows Black 1.5D - 10D R
