Specifications
Brand Name :
TOBO
Model Number :
SS 310S / UNS S31008 / 1.4845 310H / UNS S31009
Certification :
SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Place of Origin :
China
MOQ :
1PC
Price :
negotiation
Payment Terms :
T/T, Western Union, D/P, MoneyGram
Supply Ability :
980000000 pcs per month
Delivery Time :
15work days
Packaging Details :
PLY-WOODEN CASE OR PALLET
Material grade :
SS 310S / UNS S31008 / 1.4845 310H / UNS S31009
Standard :
ASME/ANSI B16.9
Size :
1/2’’~48’’(Seamless);16’’~72’’(Welded)
Manufacturing process :
Push, Press, Forge, Cast, etc.
Description

310H UNS S31009 Butt Weld Tube Fittings Stainless Steel Pipe End Caps

Stainless Steel 310, combining excellent high temperature properties with good weldability and ductility, is designed for high temperature service. SS 310 resists oxidation in continuous service at temperatures up to 1150°C provided reducing sulfur gases are not present. SS 310 is also used for intermittent service at temperatures up to 1040°C.

Stainless Steel 310S is used when the application environment involves moist corrodents in a temperature range lower than that which is normally considered “high temperature” service. The lower carbon content of SS 310S does reduce its high temperature strength compared to 310.

SS 310 SS 310S
Ni 19 – 22 19 – 22
Cr 24 – 26 24 – 26
C 0.25 max 0.08 max
Fe Balance
Mn 2 max 2 max
Si 1.50 max 1.50 max
S 0.03 max 0.03 max
P 0.045 max 0.045

Type

Butt weld fittings elbow ,reducer,tee,stub end ,cap

Standard

ASME/ANSI B16.9

Size

1/2’’~48’’(Seamless);16’’~72’’(Welded)

Wall thickness

Sch5~Sch160XXS

Manufacturing process

Push, Press, Forge, Cast, etc.

Material

Carbon steel, stainless steel, alloy steel, duplex stainless, nickel alloy steel

Carbon steel

ASTM A234 WPB, WPC;

Stainless steel

304/SUS304/UNS S30400/1.4301

304L/UNS S30403/1.4306;

304H/UNS S30409/1.4948;

309S/UNS S30908/1.4833

309H/UNS S30909;

310S/UNS S31008/1.4845;

310H/UNS S31009;

316/UNS S31600/1.4401;

316Ti/UNS S31635/1.4571;

316H/UNS S31609/1.4436;

316L/UNS S31603/1.4404;

316LN/UNS S31653;

317/UNS S31700;

317L/UNS S31703/1.4438;

321/UNS S32100/1.4541;

321H/UNS S32109;

347/UNS S34700/1.4550;

347H/UNS S34709/1.4912;

348/UNS S34800;

Alloy steel

ASTM A234 WP5/WP9/WP11/WP12/WP22/WP91;

ASTM A860 WPHY42/WPHY52/WPHY60/WPHY65;

ASTM A420 WPL3/WPL6/WPL9;

Duplex steel

ASTM A182 F51/S31803/1.4462;

ASTM A182 F53/S2507/S32750/1.4401;

ASTM A182 F55/S32760/1.4501/Zeron 100;

2205/F60/S32205;

ASTM A182 F44/S31254/254SMO/1.4547;

17-4PH/S17400/1.4542/SUS630/AISI630;

F904L/NO8904/1.4539;

725LN/310MoLN/S31050/1.4466

253MA/S30815/1.4835;

Nickel alloy steel

Alloy 200/Nickel 200/NO2200/2.4066/ASTM B366 WPN;

Alloy 201/Nickel 201/NO2201/2.4068/ASTM B366 WPNL;

Alloy 400/Monel 400/NO4400/NS111/2.4360/ASTM B366 WPNC;

Alloy K-500/Monel K-500/NO5500/2.475;

Alloy 600/Inconel 600/NO6600/NS333/2.4816;

Alloy 601/Inconel 601/NO6001/2.4851;

Alloy 625/Inconel 625/NO6625/NS336/2.4856;

Alloy 718/Inconel 718/NO7718/GH169/GH4169/2.4668;

Alloy 800/Incoloy 800/NO8800/1.4876;

Alloy 800H/Incoloy 800H/NO8810/1.4958;

Alloy 800HT/Incoloy 800HT/NO8811/1.4959;

Alloy 825/Incoloy 825/NO8825/2.4858/NS142;

Alloy 925/Incoloy 925/NO9925;

Hastelloy C/Alloy C/NO6003/2.4869/NS333;

Alloy C-276/Hastelloy C-276/N10276/2.4819;

Alloy C-4/Hastelloy C-4/NO6455/NS335/2.4610;

Alloy C-22/Hastelloy C-22/NO6022/2.4602;

Alloy C-2000/Hastelloy C-2000/NO6200/2.4675;

Alloy B/Hastelloy B/NS321/N10001;

Alloy B-2/Hastelloy B-2/N10665/NS322/2.4617;

Alloy B-3/Hastelloy B-3/N10675/2.4600;

Alloy X/Hastelloy X/NO6002/2.4665;

Alloy G-30/Hastelloy G-30/NO6030/2.4603;

Alloy X-750/Inconel X-750/NO7750/GH145/2.4669;

Alloy 20/Carpenter 20Cb3/NO8020/NS312/2.4660;

Alloy 31/NO8031/1.4562;

Alloy 901/NO9901/1.4898;

Incoloy 25-6Mo/NO8926/1.4529/Incoloy 926/Alloy 926;

Inconel 783/UNS R30783;

NAS 254NM/NO8367;

Monel 30C

Nimonic 80A/Nickel Alloy 80a/UNS N07080/NA20/2.4631/2.4952

Nimonic 263/NO7263

Nimonic 90/UNS NO7090;

Incoloy 907/GH907;

Nitronic 60/Alloy 218/UNS S21800

Package

Wooden cases, pallets, nylon bags or according to the customers' requirements

MOQ

1pcs

Delivery time

10-100 days depending on quantity

Payment terms

T/T or Western Union or LC

Shipment

FOB Tianjin/Shanghai, CFR, CIF, etc

Application

Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc

Remarks

Other materials and drawings are available.

Welcome to contact us.
