Specifications
Brand Name :
TOBO/TPCO/TISCO/VALIN/METAL
Model Number :
DIN, DIN 2391
Certification :
ISO/PED/TUV/SGS/LR/BV
Place of Origin :
China/Japan/Germany
MOQ :
100KGS
Price :
negotiable
Payment Terms :
T/T, L/C, Western Union, MoneyGram
Supply Ability :
1500 tons per month
Delivery Time :
15days->
Packaging Details :
in plastic bags then in bundles
Standard :
DIN, DIN 2391
color :
White, silver
Material :
Carbon Steel
type :
tube
Description

Honed Hydraulic Cylinder Tube DIN DIN 2391 Carbon Steel Like SAE1020 SAE1045

Quick Details

Standard:
DIN, DIN 2391
 Grade:
10#-45#, Cr-Mo alloy, ST35-ST52, 45#, 30CrMo, 34CrMo4, St52, St52.4
 Thickness:
0.8 - 50 mm
Section Shape:
Round
 Outer Diameter:
10 - 325 mm
 Place of Origin:
China
Secondary Or Not:
Non-secondary
 Application:
Hydraulic Pipe
 Technique:
Cold Drawn
Certification:
ISO9001-2008 or Third party
 Surface Treatment:
Internal honing,internal skiving and roller burnishing,external machin
 Special Pipe:
Thick Wall Pipe
Alloy Or Not:
Non-alloy
 material-1:
carbon steel like SAE1020,SAE1045,C45E
 material-2:
low alloy steel like E355,St52,SAE1026
material-3:
alloy steel like SAE4130,SAE4140,25CrMo4,

Packaging & Delivery

Packaging Details: Tubes will be tied in bundles by steel strips, Internal and external oil coating, and end plastic caps. External packing by knit bags.
Delivery Detail: 30 Days

Product Description

1. Commodity: Honed hydraulic cylinder tube

2. Types: honed tubes, skived and roller burnished tubes

3. Manufacture method: Cold rolled, Hydraulic cold drawn

4. Internal surface treatment method: honing or skiving and roller burnishing.

5. Size range: 40mm*30mm - 325mm*300mm

6. Standard&material: EN10305-1 E355,C45E,34CrMo4,42CrMo4,DIN2391-2 ST52,ST52.3,ST52.4,ASTM A519 SAE1020,SAE1045,SAE1026,SAE4130,SAE4140,etc.

7. Delivery condition: BK(+C), BKW(+LC), BKS(+SR), GBK(+A), NBK(+N).

8. OD tolerance: as per DIN2391-1, EN10305-1, ASTM A519 or as per customer's requirement.

9. ID tolerance: H7,H8,H9,H10 or given by customer.

10. Roughness of internal surface: 0.35um max for honed tubes, 0.25um max for skived&roller burnished tubes.

10. Wall Thickness tolerance (eccentricity): +/-5%

11. Ovality of OD: 0.15mm max for tubes with OD below 150mm, 0.25mm max for tubes with OD above 150mm.

12. Straightness: 0.5mm/1000mm max for tubes below 3000mm, 0.8mm/1000mm max for tubes between 3000mm and 6000mm, 1.2mm/1000mm for tubes above 6000mm.

Tolerance of ID of skived&roller burnished tubes:

ID / MM

H7

H8

H9

H10

30<ID≤50

+0.025/-0

+0.039/-0

+0.062/-0

+0.100/-0

50<ID≤80

+0.030/-0

+0.046/-0

+0.074/-0

+0.120/-0

80<ID≤120

+0.035/-0

+0.054/-0

+0.087/-0

+0.140/-0

120<ID≤180

+0.040/-0

+0.063/-0

+0.100/-0

+0.160/-0

180<ID≤250

+0.046/-0

+0.072/-0

+0.115/-0

+0.185/-0

250<ID≤315

+0.052/-0

+0.081/-0

+0.130/-0

+0.210/-0

315<ID≤400

+0.057/-0

+0.089/-0

+0.140/-0

+0.230/-0

400<ID≤500

+0.063/-0

+0.097/-0

+0.155/-0

-

TOBOGROUP deal with stainless steel welded pipe and tube already more than 10 years, every year sell
more than 80000 tons of stainless steel pipe and tube. Our client already cover more than 45 countries.
Our stainless steel seamless pipe and tube was width used in Mining, Energy, Petrochemical, Chemical
Industry, Food plant, Paper plant, Gas and Fluid Industry etc.

Why choose us!
1. We are the specialized supplier of stainless steel materials, can provide the best price!
2. We have more than 30 years experience in exporting products to worldwide countries, can provide the high quality products!
3. We have three thousand tons of stock in warehouses with abundant capital. Furthermore, we offer charge sales, credit and 7-day 24-hour services.
4. Wide excellent experiences with after-sale service.
5. Every process will be checked by responsible QC which insures every product's quality.
6. Professional packing teams which keep every packing safely.
7. Trial order can be done in very short time.
8. Samples can be provided as your requirements.

Honed Hydraulic Cylinder Tube DIN DIN 2391 Carbon Steel Like SAE1020 SAE1045Honed Hydraulic Cylinder Tube DIN DIN 2391 Carbon Steel Like SAE1020 SAE1045Honed Hydraulic Cylinder Tube DIN DIN 2391 Carbon Steel Like SAE1020 SAE1045
