Specifications
Brand Name :
TOBO
Model Number :
Nickel 200 UNS N02200 Nickel 99.2
Certification :
SGS/BV/ABS/LR/TUV/DNV/BIS/API/PED
Place of Origin :
CHINA
MOQ :
3PCS
Price :
Negotiation
Payment Terms :
T/T, L/C, Western Union
Supply Ability :
9980000PCS Per Month
Delivery Time :
15DAYS
Packaging Details :
PLY-WOODEN CASE OR PALLET
Material :
Nickel 200 UNS N02200 Nickel 99.2
Thickness: :
Sch5-Sch160, STD, XS, XXS
Standard: :
ANSI/ASTM B16.9/ B16.11
Surface Finish: :
sand blast, black painting, galvanizing finish
Manufacturing process :
Push, Press, Forge, Cast, etc.
Application :
Petroleum/Power/Chemical/Construction/Gas/Metallurgy/Shipbuilding etc
Packaging Details: :
butt welding pipe fitting commonly should be shipped in wooden cases, wooden pallets or as per customers request
Description

Nickel 200 UNS N02200 Nickel 99.2 But Weld Fittings Elbow Tee Reducer 1” To 24” SCH10S To SCH80S ASME B16.9

Nickel 200 (UNS N02200)

General Description

Nickel 200 ( UNS N02200) , a grade of pure nickel contains 99.2% nickel, has excellent mechanical properties, magnetic properties, high thermal, electrical conductivity and excellent resistance to many corrosive environment. Nickel 200 is useful in any environment below 600℉(315℃). It has highly resistance to neutral and alkaline salt solutions. Nickel 200 also has low corrosion rates in neutral and distilled water.

The applications of pure nickel includes food processing equipment, magnetostrictive devices and rechargeable batteries, computers, cellular Phone, power tools, camcorders and so on.

Chemical Composition

Alloy

Ni%

Mn%

Fe%

Si%

Cu%

C%

S%
Nickel 200 Min 99.2 Max 0.35 Max 0.4 Max 0.35 Max 0.25 Max 0.15 Max 0.01

Physical Data

Density 8.89g/cm3
Specific Heat 0.109(456 J/kg.℃)
Electrical Resistivity 0.096×10-6ohm.m
Melting Point 1435-1446℃
Thermal Conductivity 70.2 W/m-K
Mean Coeff Thermal Expansion 13.3×10-6m/m.℃

Typical Mechanical Properties

Mechanical Property

Nickel 200
Tensile Strength

462 Mpa
Yield Strength

148 Mpa
Elongation

47
