3.5 Exhaust Titanium Bends 45 Degree 90 Degree 180 Degree Titanium Elbow
3.5 Exhaust Titanium Bends 45 Degree 90 Degree 180 Degree Titanium Elbow
3.5 Exhaust Titanium Bends 45 Degree 90 Degree 180 Degree Titanium Elbow
3.5 Exhaust Titanium Bends 45 Degree 90 Degree 180 Degree Titanium Elbow
Specifications
Brand Name :
TOBO
Model Number :
Butt Weld Fittings
Certification :
ISO/PED/TUV/TISCO/VALIN/METAL
Place of Origin :
CHINA/JAPAN/GERMANY
MOQ :
10PCS
Price :
negotiable
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
30000PCS/MONTH
Delivery Time :
5-10WORKDAYS
Packaging Details :
PLY-wooden case or pallet or as for clients' requirements
Material :
Stainless Steel
Shape :
Reducing
Connection :
butt welded
Technics :
Casting
Head code :
round
Size :
Customized Size
Application :
Pipe Lines Connect
Standard :
DIN, ISO, 3A, SMS, BS, IDF, DS, BPE
Packing :
Standard Seaworthy Packing
Color :
White,Can be customed
Payment: :
Trade Assurance TT Paypal
Description

3.5" exhaust Titanium bends 45 Degree 90 Degree 180 Degree Titanium Elbow

Product Description
Product Titanium elbow
Application Motorcycle exhaust muffler
Material Gr2 pure titanium
Standard ANSI B16.5,JIS B2220,DIN2627-2628,ASME,GB/T
OD 38/45/51/60/63/70/76/80/89/102mm
Inch Size 1.5"/1.75"/2.0"/2.5"/3.0"/3.5"/4.0"/4.5"/5.0"/6.0"
Wall Thickness 1.0/1.2/1.5mm
Certificate TUV, ISO9001
Materials Titanium : Grade1,Grade2,Grade5,Grade7,Grade9,Grade12
Quality control PMI,100% ULTRASONIC TEST etc

Item DIA(C ) Thickness(B) Radius of Bending(A) Angle Material
mm inch mm inch mm inch Degree
1 38 1 1 0.0394 38 1.5 45/90 GR2 Titanium
2 45 1.75 1 0.0394 48 1.875 45/90
3 48 1.875 1 0.0394 48 1.875 45/90
4 50.8 2 1 0.0394 60 2.35 45/90
5 63.5 2.5 1 0.0394 63.5 2.5 45/90
6 63.5 2.5 1 0.0394 76.2 3 45/90
7 70 2.755 1 0.0394 70 2.755 45/90
8 76.2 3 1 0.0394 80 3.15 45/90
9 76.2 3 1 0.0394 114 4.5 45/90
10 89 3.5 1.2 0.0472 99 3.9 45/90
11 89 3.5 1.2 0.0472 114 4.5 45/90
12 102 4 1.2 0.0472 85 3.35 45/90
13 102 4 1.2 0.0472 127 5 45/90
14 102 4 1.2 0.0472 133 5.235 45/90
15 114 4.5 1.5 0.0591 114 4.5 45/90
16 114 4.5 1.5 0.0591 152 6 45/90
17 127 5 1.5 0.0591 100 3.935 45/90
18 127 5 1.5 0.0591 127 5 45/90
19 152.4 6 1.5 0.0591 152.4 6 45/90
20

CUSTOMIZATION

3.53.5

3.5
